Compatible x86 machines

Thin clients can be a good alternative to the Raspberry Pi. I have Volumio installed on a Dell Wyse 3040 thin client, available used at roughly $50 from Ebay. This particular thin client has a cheap onboard DAC for a headphone jack, 16 GB flash drive, 2 GB RAM, but unfortunately no WiFi.

Adding WiFi was about $20 extra for a USB dongle.

This is not to disparage the Raspberry Pi, or any group buys. The case for the Wyse 3040 has a rough industrial appearance, and a correspondingly low Wife Approval Factor, but it’s small enough to be tucked away somewhere out of sight.

2 Likes

HP T520
TĆ°ĆĄng thĂ­ch 3.378 100%

HP EliteDesk G1 800 mini

  • Brand: HP
  • Model: EliteDesk G1 800 mini
  • Chipset: Intel(R) Core™ i5-4570T CPU @ 2.90GHz 2.90 GHz
  • Booting from: HDD/SDD/USB
  • Confirmed image version: 3.378
1 Like
  • Brand: Toshiba
  • Model: Satelite Click Mini L9W-B
  • Chipset: Atom™ Z3735F
  • Running from: usb device
  • Confirmed image version: V3.424 (6.1.4 Kernel, beta test)

What is working:

  • Bluetooth
  • Internal Audio
  • Volume buttons
  • Power Button
  • WiFi
  • Docking keyboard
  • LCD + Touchscreen
  • Both SD card slots (tablet and Docking)

Glad to be here. I already use Volumio on a Rock4 in my car. I would like to switch to more robust and easier equipment in the management of the ignition and extinction phases, among other things. there is this at an affordable price which can be managed by Carpc power supplies. This Asrock J4125-ITX has Spidif optics. Do you think that volumio will be able to agree? Thanks in advance Bernard.

Here, https://www.asrock.com/mb/Intel/J4125-ITX/

Minis Forum N40 - Intel Celeron N4020 - 3 x USB 3.0 - LAN 1 Gbit/s - wifi AC 2.4 / 5 Ghz - 433 Mbit/s with Bluetooth - RAM 4GB - HDMI - VGA
EMMC 64 GB - SD Card Reader - M.2 SATA NGFF disk.
Work ok.

Brand: Intel NUC8i5PNB bare board
Model: i5-8365u
Boot: Local 128GB SSD M.2 or USB (legacy and UEFI Bios)
Version: 3.429 (I might be wrong here, dont remember :slight_smile: )

After inserting USB, selected boot priority in Bios. Everything went very smooth and quick (within a minute I had Startup wizard). In System setting you can select copy installation to SSD (awesome feature, lets you modify/edit .css on usb and after you happy with UI, you can copy it).

Kiosk mode looks great on wide screen 14.1" LCD with some issues

Touch works without any plugins (only annoyance is the mouse cursor visible).
Now playing plugin does not work correctly for me, I will post in other thread.

Danny

Brand: Dell
Model: Dell Latitude 3189
Chipset: Intel(R) Pentium(R) CPU N4200 @ 1.10GHz
Boot: USB and M.2
Version: V3.349
Working:

  • WiFi
  • BT
  • Keyboard
  • Touchscreen
  • FN Volume control

Remark: Hotspot and internal Wifi card don’t work together. You need to disable the hotspot.

Brand: HP
See: HP EliteDesk G1 800 Mini
Includes: WiFI Intel Dual Band Wireless AC-3168, Model 3168NGW (M.2 Key a+e)
Adds: WiFi 5.0 and BT 4.0
(e.g. AsRock DeskMini WiFi Kit)

  • Remove the heatsink & fan
  • Remove the 2 breakout bits at the backpanel
  • Remove the disk
  • Mount the WiFi kit
  • Remount fan & heatsink
  • Remount disk

Works ootb

1 Like

Brand: Compaq
Model: Presario Laptop
Chipset:?
USB hard drive: Western Digital 1TB
DAC: SMSL DO100

Works great (kicks ass, actually).

1 Like

2 posts were merged into an existing topic: X86 Hardware issues (WiFi, DAC, Disks, Boot etc.)

Brand : Pipo
Model : X9
Chipset : Intel Z3736F Quad Core up to 1.83GHz
Running from local ROM
Image : Volumio-3.569-2023-10-20-x86_amd64

Brand: Acepc
Model: T11
Intel(R) Atom™ x5-Z8350 CPU @ 1.44GHz
Wifi/Bluetooth Realtek rtl8821cu
RTL8111/8168/8411 PCI Express Gigabit Ethernet Controller
8GB RAM DIMM DDR3 1066 MHz
128GB MMC SSD
Audio Output: HDMI

Works with Wolumio 3.611 on HDMI2 but with restrictions. Can’t play 44.1kZ, 88.2kHz, and 176.4kHz files. Workaround by resampling to a supported freq. (ie 48kHz, 96kH and 192kHz)

Intel NUC NUC8CCHK Rugged ( 45 euro )

Intel Celeron N3350 - RAM 4GB - EMMC 64 GB ( system Volumio ) - Intel Corporation Dual Band Wireless-AC 3168NGW + Intel Corporation I211 Gigabit Network Connection

Works with 12 V - 3A or 5A and

  • Disk NVME Samsung 980 - 1TB ( Music )
  • DAC USB SMSL PO100 AK

This set works without any problems.

Przechwycenie obrazu ekranu_2024-08-09_00-50-08
