it’s already written in code (bash), the source is me.
got it today, I confirm there is a problem with the drivers made by Raspberry Pi for this model.
Let’s see if I can help to have it fixed by them, providing some parameters for the timing
Thanks a lot @Darmur! I’ve checked the github issues and it seemes they already fixed this driver issue but it requires a kernel update:
1 Like
good, I’ll take care of patching the driver on kernel 6.1.69
@danidemo please try to enable test mode and update to 3.622
with the patched driver, the 11.9" display works fine.
Also the rotation parameter works fine
dtoverlay=vc4-kms-v3d
dtoverlay=vc4-kms-dsi-waveshare-panel,11_9_inch,rotation=270
I tried on RPi2 and I can use the touch-display plugin
However, when connected to a Pi5, I can see the boot text if the touch-display plugin is disabled. As soon as I enable it, the screen goes blank and the UI is not loaded. The plugin is the version 3.3.8, that already adds the file /etc/X11/xorg.conf.d/99-vc4.conf
@gvolt any clue?
Is it the same without the rotation parameter, i.e.when using just dtoverlay=vc4-kms-dsi-waveshare-panel,11_9_inch?
Please post the content of “/boot/config.txt”, “/boot/volumioconfig.txt” and “/boot/userconfig.txt” and also the output of
cat /var/log/Xorg.0.log
yes, it’s the same with no rotation
[ 68.691]
X.Org X Server 1.20.4
X Protocol Version 11, Revision 0
[ 68.691] Build Operating System: Linux 5.4.0-109-generic armv8l Raspbian
[ 68.691] Current Operating System: Linux volumio-usb 6.1.69-v8+ #1710 SMP PREEMPT Thu Dec 21 13:21:40 GMT 2023 aarch64
[ 68.691] Kernel command line: reboot=w coherent_pool=1M 8250.nr_uarts=1 pci=pcie_bus_safe snd_bcm2835.enable_compat_alsa=0 snd_bcm2835.enable_hdmi=1 smsc95xx.macaddr=D8:3A:DD:7B:C6:00 vc_mem.mem_base=0x3fc00000 vc_mem.mem_size=0x40000000 splash plymouth.ignore-serial-consoles dwc_otg.fiq_enable=1 dwc_otg.fiq_fsm_enable=1 dwc_otg.fiq_fsm_mask=0xF dwc_otg.nak_holdoff=1 quiet console=ttyAMA0,115200 console=tty1 imgpart=UUID=09e9eb41-a375-4504-bd95-b9fb31bf869c imgfile=/volumio_current.sqsh bootpart=UUID=1580-EA53 datapart=UUID=5f69cd19-e2eb-4159-a4fb-faef243916c3 bootconfig=cmdline.txt pcie_aspm=off pci=pcie_bus_safe bootdelay=5 logo.nologo vt.global_cursor_default=0 net.ifnames=0 snd-bcm2835.enable_compat_alsa= snd_bcm2835.enable_hdmi=1 snd_bcm2835.enable_headphones=1 loglevel=0
[ 68.691] Build Date: 04 April 2023 07:50:56AM
[ 68.691] xorg-server 2:1.20.4-1+rpt4+deb10u9 (https://www.debian.org/support)
[ 68.691] Current version of pixman: 0.36.0
[ 68.691] Before reporting problems, check http://wiki.x.org
to make sure that you have the latest version.
[ 68.691] Markers: (--) probed, (**) from config file, (==) default setting,
(++) from command line, (!!) notice, (II) informational,
(WW) warning, (EE) error, (NI) not implemented, (??) unknown.
[ 68.691] (==) Log file: "/var/log/Xorg.0.log", Time: Thu Feb 15 12:18:09 2024
[ 68.744] (==) Using config directory: "/etc/X11/xorg.conf.d"
[ 68.744] (==) Using system config directory "/usr/share/X11/xorg.conf.d"
[ 68.792] (==) No Layout section. Using the first Screen section.
[ 68.792] (==) No screen section available. Using defaults.
[ 68.792] (**) |-->Screen "Default Screen Section" (0)
[ 68.792] (**) | |-->Monitor "<default monitor>"
[ 68.803] (==) No monitor specified for screen "Default Screen Section".
Using a default monitor configuration.
[ 68.803] (==) Automatically adding devices
[ 68.803] (==) Automatically enabling devices
[ 68.803] (==) Automatically adding GPU devices
[ 68.813] (==) Max clients allowed: 256, resource mask: 0x1fffff
[ 68.830] (WW) The directory "/usr/share/fonts/X11/cyrillic" does not exist.
[ 68.830] Entry deleted from font path.
[ 68.856] (==) FontPath set to:
/usr/share/fonts/X11/misc,
/usr/share/fonts/X11/100dpi/:unscaled,
/usr/share/fonts/X11/75dpi/:unscaled,
/usr/share/fonts/X11/Type1,
/usr/share/fonts/X11/100dpi,
/usr/share/fonts/X11/75dpi,
built-ins
[ 68.856] (==) ModulePath set to "/usr/lib/xorg/modules"
[ 68.856] (II) The server relies on udev to provide the list of input devices.
If no devices become available, reconfigure udev or disable AutoAddDevices.
[ 68.856] (II) Loader magic: 0x1fdf80
[ 68.856] (II) Module ABI versions:
[ 68.856] X.Org ANSI C Emulation: 0.4
[ 68.856] X.Org Video Driver: 24.0
[ 68.856] X.Org XInput driver : 24.1
[ 68.856] X.Org Server Extension : 10.0
[ 68.857] (--) using VT number 2
[ 68.857] (II) systemd-logind: logind integration requires -keeptty and -keeptty was not provided, disabling logind integration
[ 68.858] (II) xfree86: Adding drm device (/dev/dri/card1)
[ 68.858] (II) xfree86: Adding drm device (/dev/dri/card0)
[ 68.858] (II) xfree86: Adding drm device (/dev/dri/card2)
[ 68.859] (**) OutputClass "vc4" setting /dev/dri/card2 as PrimaryGPU
[ 68.859] (II) LoadModule: "glx"
[ 68.861] (II) Loading /usr/lib/xorg/modules/extensions/libglx.so
[ 68.912] (II) Module glx: vendor="X.Org Foundation"
[ 68.912] compiled for 1.20.4, module version = 1.0.0
[ 68.912] ABI class: X.Org Server Extension, version 10.0
[ 68.912] (II) Applying OutputClass "vc4" to /dev/dri/card2
[ 68.912] loading driver: modesetting
[ 68.912] (==) Matched modesetting as autoconfigured driver 0
[ 68.912] (==) Matched fbdev as autoconfigured driver 1
[ 68.912] (==) Assigned the driver to the xf86ConfigLayout
[ 68.912] (II) LoadModule: "modesetting"
[ 68.921] (II) Loading /usr/lib/xorg/modules/drivers/modesetting_drv.so
[ 68.929] (II) Module modesetting: vendor="X.Org Foundation"
[ 68.929] compiled for 1.20.4, module version = 1.20.4
[ 68.929] Module class: X.Org Video Driver
[ 68.929] ABI class: X.Org Video Driver, version 24.0
[ 68.929] (II) LoadModule: "fbdev"
[ 68.929] (II) Loading /usr/lib/xorg/modules/drivers/fbdev_drv.so
[ 68.935] (II) Module fbdev: vendor="X.Org Foundation"
[ 68.935] compiled for 1.20.3, module version = 0.5.0
[ 68.935] Module class: X.Org Video Driver
[ 68.935] ABI class: X.Org Video Driver, version 24.0
[ 68.935] (II) modesetting: Driver for Modesetting Kernel Drivers: kms
[ 68.935] (II) FBDEV: driver for framebuffer: fbdev
[ 68.938] (II) modeset(0): using drv /dev/dri/card2
[ 68.938] (WW) Falling back to old probe method for fbdev
[ 68.938] (II) Loading sub module "fbdevhw"
[ 68.938] (II) LoadModule: "fbdevhw"
[ 68.938] (II) Loading /usr/lib/xorg/modules/libfbdevhw.so
[ 68.948] (II) Module fbdevhw: vendor="X.Org Foundation"
[ 68.948] compiled for 1.20.4, module version = 0.0.2
[ 68.948] ABI class: X.Org Video Driver, version 24.0
[ 68.953] (II) modeset(G0): using drv /dev/dri/card1
[ 68.953] (II) modeset(0): Creating default Display subsection in Screen section
"Default Screen Section" for depth/fbbpp 24/32
[ 68.953] (==) modeset(0): Depth 24, (==) framebuffer bpp 32
[ 68.953] (II) Applying OutputClass "vc4" options to /dev/dri/card2
[ 68.953] (==) modeset(0): RGB weight 888
[ 68.953] (==) modeset(0): Default visual is TrueColor
[ 68.953] (II) Loading sub module "glamoregl"
[ 68.953] (II) LoadModule: "glamoregl"
[ 68.953] (II) Loading /usr/lib/xorg/modules/libglamoregl.so
[ 69.031] (II) Module glamoregl: vendor="X.Org Foundation"
[ 69.031] compiled for 1.20.4, module version = 1.0.1
[ 69.031] ABI class: X.Org ANSI C Emulation, version 0.4
[ 70.608] (II) modeset(0): Refusing to try glamor on llvmpipe
[ 70.609] (EE) modeset(0): glamor initialization failed
[ 70.609] (II) modeset(0): ShadowFB: preferred NO, enabled NO
[ 70.611] (II) modeset(0): Output HDMI-1 has no monitor section
[ 70.613] (II) modeset(0): Output HDMI-2 has no monitor section
[ 70.614] (II) modeset(0): EDID for output HDMI-1
[ 70.616] (II) modeset(0): EDID for output HDMI-2
[ 70.616] (II) modeset(0): Output HDMI-1 disconnected
[ 70.616] (II) modeset(0): Output HDMI-2 disconnected
[ 70.616] (WW) modeset(0): No outputs definitely connected, trying again...
[ 70.616] (II) modeset(0): Output HDMI-1 disconnected
[ 70.616] (II) modeset(0): Output HDMI-2 disconnected
[ 70.616] (WW) modeset(0): Unable to find connected outputs - setting 1024x768 initial framebuffer
[ 70.616] (==) modeset(0): Using gamma correction (1.0, 1.0, 1.0)
[ 70.616] (==) modeset(0): DPI set to (96, 96)
[ 70.616] (II) Loading sub module "fb"
[ 70.616] (II) LoadModule: "fb"
[ 70.616] (II) Loading /usr/lib/xorg/modules/libfb.so
[ 72.732] (II) Module fb: vendor="X.Org Foundation"
[ 72.732] compiled for 1.20.4, module version = 1.0.0
[ 72.732] ABI class: X.Org ANSI C Emulation, version 0.4
[ 72.732] (==) modeset(G0): Depth 24, (==) framebuffer bpp 32
[ 72.732] (==) modeset(G0): RGB weight 888
[ 72.732] (==) modeset(G0): Default visual is TrueColor
[ 72.732] (II) Loading sub module "glamoregl"
[ 72.732] (II) LoadModule: "glamoregl"
[ 72.732] (II) Loading /usr/lib/xorg/modules/libglamoregl.so
[ 72.732] (II) Module glamoregl: vendor="X.Org Foundation"
[ 72.732] compiled for 1.20.4, module version = 1.0.1
[ 72.732] ABI class: X.Org ANSI C Emulation, version 0.4
[ 72.745] (II) modeset(G0): Refusing to try glamor on llvmpipe
[ 72.745] (EE) modeset(G0): glamor initialization failed
[ 72.745] (II) modeset(G0): ShadowFB: preferred NO, enabled NO
[ 72.746] (II) modeset(G0): Output DSI-1-2 has no monitor section
[ 72.746] (II) modeset(G0): EDID for output DSI-1-2
[ 72.746] (II) modeset(G0): Printing probed modes for output DSI-1-2
[ 72.746] (II) modeset(G0): Modeline "320x1480"x60.2 50.00 320 380 440 500 1480 1540 1600 1660 (100.0 kHz eP)
[ 72.746] (==) modeset(G0): Using gamma correction (1.0, 1.0, 1.0)
[ 72.746] (==) modeset(G0): DPI set to (96, 96)
[ 72.746] (II) Loading sub module "fb"
[ 72.746] (II) LoadModule: "fb"
[ 72.746] (II) Loading /usr/lib/xorg/modules/libfb.so
[ 72.746] (II) Module fb: vendor="X.Org Foundation"
[ 72.746] compiled for 1.20.4, module version = 1.0.0
[ 72.746] ABI class: X.Org ANSI C Emulation, version 0.4
[ 72.746] (II) UnloadModule: "fbdev"
[ 72.746] (II) Unloading fbdev
[ 72.746] (II) UnloadSubModule: "fbdevhw"
[ 72.746] (II) Unloading fbdevhw
[ 80.187] (==) modeset(G0): Backing store enabled
[ 80.187] (==) modeset(G0): Silken mouse enabled
[ 80.210] (II) modeset(G0): Initializing kms color map for depth 24, 8 bpc.
[ 80.210] (==) modeset(G0): DPMS enabled
[ 80.211] (==) modeset(0): Backing store enabled
[ 80.211] (==) modeset(0): Silken mouse enabled
[ 80.211] (II) modeset(0): Initializing kms color map for depth 24, 8 bpc.
[ 80.211] (==) modeset(0): DPMS enabled
[ 80.211] (WW) modeset(0): Option "PrimaryGPU" is not used
[ 80.211] (II) Initializing extension Generic Event Extension
[ 80.212] (II) Initializing extension SHAPE
[ 80.212] (II) Initializing extension MIT-SHM
[ 80.212] (II) Initializing extension XInputExtension
[ 80.220] (II) Initializing extension XTEST
[ 80.221] (II) Initializing extension BIG-REQUESTS
[ 80.221] (II) Initializing extension SYNC
[ 80.221] (II) Initializing extension XKEYBOARD
[ 80.222] (II) Initializing extension XC-MISC
[ 80.222] (II) Initializing extension SECURITY
[ 80.222] (II) Initializing extension XFIXES
[ 80.223] (II) Initializing extension RENDER
[ 80.223] (II) Initializing extension RANDR
[ 80.224] (II) Initializing extension COMPOSITE
[ 80.224] (II) Initializing extension DAMAGE
[ 80.224] (II) Initializing extension MIT-SCREEN-SAVER
[ 80.225] (II) Initializing extension DOUBLE-BUFFER
[ 80.225] (II) Initializing extension RECORD
[ 80.225] (II) Initializing extension DPMS
[ 80.226] (II) Initializing extension Present
[ 80.226] (II) Initializing extension DRI3
[ 80.226] (II) Initializing extension X-Resource
[ 80.226] (II) Initializing extension XVideo
[ 80.226] (II) Initializing extension XVideo-MotionCompensation
[ 80.226] (II) Initializing extension SELinux
[ 80.226] (II) SELinux: Disabled on system
[ 80.226] (II) Initializing extension GLX
[ 80.227] (II) AIGLX: Screen 0 is not DRI2 capable
[ 80.304] (II) IGLX: Loaded and initialized swrast
[ 80.304] (II) GLX: Initialized DRISWRAST GL provider for screen 0
[ 80.304] (II) Initializing extension XFree86-VidModeExtension
[ 80.305] (II) Initializing extension XFree86-DGA
[ 80.305] (II) Initializing extension XFree86-DRI
[ 80.310] (II) Initializing extension DRI2
[ 83.413] (II) modeset(G0): Damage tracking initialized
[ 83.414] (II) modeset(0): Damage tracking initialized
[ 85.692] (II) config/udev: Adding input device pwr_button (/dev/input/event0)
[ 85.693] (**) pwr_button: Applying InputClass "libinput keyboard catchall"
[ 85.693] (II) LoadModule: "libinput"
[ 85.693] (II) Loading /usr/lib/xorg/modules/input/libinput_drv.so
[ 85.718] (II) Module libinput: vendor="X.Org Foundation"
[ 85.718] compiled for 1.20.3, module version = 0.28.2
[ 85.718] Module class: X.Org XInput Driver
[ 85.718] ABI class: X.Org XInput driver, version 24.1
[ 85.718] (II) Using input driver 'libinput' for 'pwr_button'
[ 85.718] (**) pwr_button: always reports core events
[ 85.718] (**) Option "Device" "/dev/input/event0"
[ 85.718] (**) Option "_source" "server/udev"
[ 85.744] (II) event0 - pwr_button: is tagged by udev as: Keyboard
[ 85.744] (II) event0 - pwr_button: device is a keyboard
[ 85.744] (II) event0 - pwr_button: device removed
[ 85.764] (**) Option "config_info" "udev:/sys/devices/platform/pwr_button/input/input0/event0"
[ 85.764] (II) XINPUT: Adding extended input device "pwr_button" (type: KEYBOARD, id 6)
[ 85.764] (**) Option "xkb_model" "pc105"
[ 85.764] (**) Option "xkb_layout" "us"
[ 85.765] (II) event0 - pwr_button: is tagged by udev as: Keyboard
[ 85.765] (II) event0 - pwr_button: device is a keyboard
[ 85.766] (II) config/udev: Adding input device vc4-hdmi-0 (/dev/input/event1)
[ 85.766] (**) vc4-hdmi-0: Applying InputClass "libinput keyboard catchall"
[ 85.766] (II) Using input driver 'libinput' for 'vc4-hdmi-0'
[ 85.766] (**) vc4-hdmi-0: always reports core events
[ 85.766] (**) Option "Device" "/dev/input/event1"
[ 85.766] (**) Option "_source" "server/udev"
[ 85.767] (II) event1 - vc4-hdmi-0: is tagged by udev as: Keyboard Pointingstick
[ 85.767] (II) event1 - vc4-hdmi-0: device is a pointer
[ 85.767] (II) event1 - vc4-hdmi-0: device is a keyboard
[ 85.767] (II) event1 - vc4-hdmi-0: device removed
[ 85.796] (II) libinput: vc4-hdmi-0: needs a virtual subdevice
[ 85.796] (**) Option "config_info" "udev:/sys/devices/platform/soc/107c701400.hdmi/rc/rc0/input1/event1"
[ 85.796] (II) XINPUT: Adding extended input device "vc4-hdmi-0" (type: MOUSE, id 7)
[ 85.796] (**) Option "AccelerationScheme" "none"
[ 85.796] (**) vc4-hdmi-0: (accel) selected scheme none/0
[ 85.796] (**) vc4-hdmi-0: (accel) acceleration factor: 2.000
[ 85.796] (**) vc4-hdmi-0: (accel) acceleration threshold: 4
[ 85.797] (II) event1 - vc4-hdmi-0: is tagged by udev as: Keyboard Pointingstick
[ 85.798] (II) event1 - vc4-hdmi-0: device is a pointer
[ 85.798] (II) event1 - vc4-hdmi-0: device is a keyboard
[ 85.798] (II) config/udev: Adding input device vc4-hdmi-1 (/dev/input/event2)
[ 85.798] (**) vc4-hdmi-1: Applying InputClass "libinput keyboard catchall"
[ 85.798] (II) Using input driver 'libinput' for 'vc4-hdmi-1'
[ 85.798] (**) vc4-hdmi-1: always reports core events
[ 85.798] (**) Option "Device" "/dev/input/event2"
[ 85.799] (**) Option "_source" "server/udev"
[ 85.800] (II) event2 - vc4-hdmi-1: is tagged by udev as: Keyboard Pointingstick
[ 85.800] (II) event2 - vc4-hdmi-1: device is a pointer
[ 85.800] (II) event2 - vc4-hdmi-1: device is a keyboard
[ 85.801] (II) event2 - vc4-hdmi-1: device removed
[ 85.816] (II) libinput: vc4-hdmi-1: needs a virtual subdevice
[ 85.816] (**) Option "config_info" "udev:/sys/devices/platform/soc/107c706400.hdmi/rc/rc1/input2/event2"
[ 85.816] (II) XINPUT: Adding extended input device "vc4-hdmi-1" (type: MOUSE, id 8)
[ 85.816] (**) Option "AccelerationScheme" "none"
[ 85.816] (**) vc4-hdmi-1: (accel) selected scheme none/0
[ 85.816] (**) vc4-hdmi-1: (accel) acceleration factor: 2.000
[ 85.816] (**) vc4-hdmi-1: (accel) acceleration threshold: 4
[ 85.817] (II) event2 - vc4-hdmi-1: is tagged by udev as: Keyboard Pointingstick
[ 85.818] (II) event2 - vc4-hdmi-1: device is a pointer
[ 85.818] (II) event2 - vc4-hdmi-1: device is a keyboard
[ 85.823] (**) vc4-hdmi-0: Applying InputClass "libinput keyboard catchall"
[ 85.823] (II) Using input driver 'libinput' for 'vc4-hdmi-0'
[ 85.823] (**) vc4-hdmi-0: always reports core events
[ 85.823] (**) Option "Device" "/dev/input/event1"
[ 85.823] (**) Option "_source" "_driver/libinput"
[ 85.823] (II) libinput: vc4-hdmi-0: is a virtual subdevice
[ 85.824] (**) Option "config_info" "udev:/sys/devices/platform/soc/107c701400.hdmi/rc/rc0/input1/event1"
[ 85.824] (II) XINPUT: Adding extended input device "vc4-hdmi-0" (type: KEYBOARD, id 9)
[ 85.824] (**) Option "xkb_model" "pc105"
[ 85.824] (**) Option "xkb_layout" "us"
[ 85.824] (**) vc4-hdmi-1: Applying InputClass "libinput keyboard catchall"
[ 85.824] (II) Using input driver 'libinput' for 'vc4-hdmi-1'
[ 85.824] (**) vc4-hdmi-1: always reports core events
[ 85.824] (**) Option "Device" "/dev/input/event2"
[ 85.824] (**) Option "_source" "_driver/libinput"
[ 85.824] (II) libinput: vc4-hdmi-1: is a virtual subdevice
[ 85.824] (**) Option "config_info" "udev:/sys/devices/platform/soc/107c706400.hdmi/rc/rc1/input2/event2"
[ 85.824] (II) XINPUT: Adding extended input device "vc4-hdmi-1" (type: KEYBOARD, id 10)
[ 85.824] (**) Option "xkb_model" "pc105"
[ 85.824] (**) Option "xkb_layout" "us"
[ 85.826] (II) event0 - pwr_button: device removed
[ 85.844] (II) event1 - vc4-hdmi-0: device removed
[ 85.860] (II) event2 - vc4-hdmi-1: device removed
[ 85.876] (II) UnloadModule: "libinput"
[ 85.876] (II) UnloadModule: "libinput"
[ 85.876] (II) UnloadModule: "libinput"
[ 85.876] (II) UnloadModule: "libinput"
[ 85.877] (II) UnloadModule: "libinput"
[ 85.881] (II) modeset(G0): Initializing kms color map for depth 24, 8 bpc.
[ 85.881] (==) modeset(G0): DPMS enabled
[ 85.882] (II) modeset(0): Initializing kms color map for depth 24, 8 bpc.
[ 85.883] (==) modeset(0): DPMS enabled
[ 85.883] (II) Initializing extension Generic Event Extension
[ 85.883] (II) Initializing extension SHAPE
[ 85.883] (II) Initializing extension MIT-SHM
[ 85.883] (II) Initializing extension XInputExtension
[ 85.884] (II) Initializing extension XTEST
[ 85.884] (II) Initializing extension BIG-REQUESTS
[ 85.884] (II) Initializing extension SYNC
[ 85.885] (II) Initializing extension XKEYBOARD
[ 85.885] (II) Initializing extension XC-MISC
[ 85.885] (II) Initializing extension SECURITY
[ 85.886] (II) Initializing extension XFIXES
[ 85.886] (II) Initializing extension RENDER
[ 85.886] (II) Initializing extension RANDR
[ 85.887] (II) Initializing extension COMPOSITE
[ 85.887] (II) Initializing extension DAMAGE
[ 85.887] (II) Initializing extension MIT-SCREEN-SAVER
[ 85.888] (II) Initializing extension DOUBLE-BUFFER
[ 85.888] (II) Initializing extension RECORD
[ 85.888] (II) Initializing extension DPMS
[ 85.889] (II) Initializing extension Present
[ 85.889] (II) Initializing extension DRI3
[ 85.889] (II) Initializing extension X-Resource
[ 85.889] (II) Initializing extension XVideo
[ 85.889] (II) Initializing extension XVideo-MotionCompensation
[ 85.889] (II) Initializing extension SELinux
[ 85.889] (II) SELinux: Disabled on system
[ 85.889] (II) Initializing extension GLX
[ 85.890] (II) AIGLX: Screen 0 is not DRI2 capable
[ 85.896] (II) IGLX: Loaded and initialized swrast
[ 85.896] (II) GLX: Initialized DRISWRAST GL provider for screen 0
[ 85.896] (II) Initializing extension XFree86-VidModeExtension
[ 85.897] (II) Initializing extension XFree86-DGA
[ 85.897] (II) Initializing extension XFree86-DRI
[ 85.897] (II) Initializing extension DRI2
[ 85.898] (II) modeset(G0): Damage tracking initialized
[ 85.898] (II) modeset(0): Damage tracking initialized
[ 85.958] (II) config/udev: Adding input device pwr_button (/dev/input/event0)
[ 85.958] (**) pwr_button: Applying InputClass "libinput keyboard catchall"
[ 85.958] (II) Using input driver 'libinput' for 'pwr_button'
[ 85.958] (**) pwr_button: always reports core events
[ 85.958] (**) Option "Device" "/dev/input/event0"
[ 85.958] (**) Option "_source" "server/udev"
[ 85.960] (II) event0 - pwr_button: is tagged by udev as: Keyboard
[ 85.960] (II) event0 - pwr_button: device is a keyboard
[ 85.960] (II) event0 - pwr_button: device removed
[ 85.980] (**) Option "config_info" "udev:/sys/devices/platform/pwr_button/input/input0/event0"
[ 85.980] (**) Option "xkb_model" "pc105"
[ 85.980] (**) Option "xkb_layout" "us"
[ 85.981] (II) event0 - pwr_button: is tagged by udev as: Keyboard
[ 85.981] (II) event0 - pwr_button: device is a keyboard
[ 85.982] (II) config/udev: Adding input device vc4-hdmi-0 (/dev/input/event1)
[ 85.982] (**) vc4-hdmi-0: Applying InputClass "libinput keyboard catchall"
[ 85.982] (II) Using input driver 'libinput' for 'vc4-hdmi-0'
[ 85.982] (**) vc4-hdmi-0: always reports core events
[ 85.982] (**) Option "Device" "/dev/input/event1"
[ 85.982] (**) Option "_source" "server/udev"
[ 85.983] (II) event1 - vc4-hdmi-0: is tagged by udev as: Keyboard Pointingstick
[ 85.983] (II) event1 - vc4-hdmi-0: device is a pointer
[ 85.983] (II) event1 - vc4-hdmi-0: device is a keyboard
[ 85.984] (II) event1 - vc4-hdmi-0: device removed
[ 86.016] (II) libinput: vc4-hdmi-0: needs a virtual subdevice
[ 86.016] (**) Option "config_info" "udev:/sys/devices/platform/soc/107c701400.hdmi/rc/rc0/input1/event1"
[ 86.016] (**) Option "AccelerationScheme" "none"
[ 86.016] (**) vc4-hdmi-0: (accel) selected scheme none/0
[ 86.016] (**) vc4-hdmi-0: (accel) acceleration factor: 2.000
[ 86.016] (**) vc4-hdmi-0: (accel) acceleration threshold: 4
[ 86.017] (II) event1 - vc4-hdmi-0: is tagged by udev as: Keyboard Pointingstick
[ 86.018] (II) event1 - vc4-hdmi-0: device is a pointer
[ 86.018] (II) event1 - vc4-hdmi-0: device is a keyboard
[ 86.019] (II) config/udev: Adding input device vc4-hdmi-1 (/dev/input/event2)
[ 86.019] (**) vc4-hdmi-1: Applying InputClass "libinput keyboard catchall"
[ 86.019] (II) Using input driver 'libinput' for 'vc4-hdmi-1'
[ 86.019] (**) vc4-hdmi-1: always reports core events
[ 86.019] (**) Option "Device" "/dev/input/event2"
[ 86.019] (**) Option "_source" "server/udev"
[ 86.021] (II) event2 - vc4-hdmi-1: is tagged by udev as: Keyboard Pointingstick
[ 86.021] (II) event2 - vc4-hdmi-1: device is a pointer
[ 86.021] (II) event2 - vc4-hdmi-1: device is a keyboard
[ 86.022] (II) event2 - vc4-hdmi-1: device removed
[ 86.040] (II) libinput: vc4-hdmi-1: needs a virtual subdevice
[ 86.040] (**) Option "config_info" "udev:/sys/devices/platform/soc/107c706400.hdmi/rc/rc1/input2/event2"
[ 86.040] (**) Option "AccelerationScheme" "none"
[ 86.040] (**) vc4-hdmi-1: (accel) selected scheme none/0
[ 86.040] (**) vc4-hdmi-1: (accel) acceleration factor: 2.000
[ 86.040] (**) vc4-hdmi-1: (accel) acceleration threshold: 4
[ 86.042] (II) event2 - vc4-hdmi-1: is tagged by udev as: Keyboard Pointingstick
[ 86.042] (II) event2 - vc4-hdmi-1: device is a pointer
[ 86.042] (II) event2 - vc4-hdmi-1: device is a keyboard
[ 86.049] (**) vc4-hdmi-0: Applying InputClass "libinput keyboard catchall"
[ 86.049] (II) Using input driver 'libinput' for 'vc4-hdmi-0'
[ 86.049] (**) vc4-hdmi-0: always reports core events
[ 86.049] (**) Option "Device" "/dev/input/event1"
[ 86.049] (**) Option "_source" "_driver/libinput"
[ 86.049] (II) libinput: vc4-hdmi-0: is a virtual subdevice
[ 86.049] (**) Option "config_info" "udev:/sys/devices/platform/soc/107c701400.hdmi/rc/rc0/input1/event1"
[ 86.049] (**) Option "xkb_model" "pc105"
[ 86.049] (**) Option "xkb_layout" "us"
[ 86.049] (**) vc4-hdmi-1: Applying InputClass "libinput keyboard catchall"
[ 86.049] (II) Using input driver 'libinput' for 'vc4-hdmi-1'
[ 86.049] (**) vc4-hdmi-1: always reports core events
[ 86.049] (**) Option "Device" "/dev/input/event2"
[ 86.049] (**) Option "_source" "_driver/libinput"
[ 86.049] (II) libinput: vc4-hdmi-1: is a virtual subdevice
[ 86.049] (**) Option "config_info" "udev:/sys/devices/platform/soc/107c706400.hdmi/rc/rc1/input2/event2"
[ 86.049] (**) Option "xkb_model" "pc105"
[ 86.049] (**) Option "xkb_layout" "us"
[ 86.051] (II) event0 - pwr_button: device removed
[ 86.076] (II) event1 - vc4-hdmi-0: device removed
[ 86.104] (II) event2 - vc4-hdmi-1: device removed
[ 86.124] (II) UnloadModule: "libinput"
[ 86.124] (II) UnloadModule: "libinput"
[ 86.124] (II) UnloadModule: "libinput"
[ 86.124] (II) UnloadModule: "libinput"
[ 86.125] (II) UnloadModule: "libinput"
[ 86.129] (II) modeset(G0): Initializing kms color map for depth 24, 8 bpc.
[ 86.129] (==) modeset(G0): DPMS enabled
[ 86.131] (II) modeset(0): Initializing kms color map for depth 24, 8 bpc.
[ 86.131] (==) modeset(0): DPMS enabled
[ 86.131] (II) Initializing extension Generic Event Extension
[ 86.131] (II) Initializing extension SHAPE
[ 86.131] (II) Initializing extension MIT-SHM
[ 86.132] (II) Initializing extension XInputExtension
[ 86.132] (II) Initializing extension XTEST
[ 86.133] (II) Initializing extension BIG-REQUESTS
[ 86.133] (II) Initializing extension SYNC
[ 86.133] (II) Initializing extension XKEYBOARD
[ 86.134] (II) Initializing extension XC-MISC
[ 86.134] (II) Initializing extension SECURITY
[ 86.134] (II) Initializing extension XFIXES
[ 86.135] (II) Initializing extension RENDER
[ 86.135] (II) Initializing extension RANDR
[ 86.136] (II) Initializing extension COMPOSITE
[ 86.136] (II) Initializing extension DAMAGE
[ 86.136] (II) Initializing extension MIT-SCREEN-SAVER
[ 86.137] (II) Initializing extension DOUBLE-BUFFER
[ 86.137] (II) Initializing extension RECORD
[ 86.137] (II) Initializing extension DPMS
[ 86.138] (II) Initializing extension Present
[ 86.138] (II) Initializing extension DRI3
[ 86.138] (II) Initializing extension X-Resource
[ 86.138] (II) Initializing extension XVideo
[ 86.139] (II) Initializing extension XVideo-MotionCompensation
[ 86.139] (II) Initializing extension SELinux
[ 86.139] (II) SELinux: Disabled on system
[ 86.139] (II) Initializing extension GLX
[ 86.139] (II) AIGLX: Screen 0 is not DRI2 capable
[ 86.145] (II) IGLX: Loaded and initialized swrast
[ 86.145] (II) GLX: Initialized DRISWRAST GL provider for screen 0
[ 86.145] (II) Initializing extension XFree86-VidModeExtension
[ 86.145] (II) Initializing extension XFree86-DGA
[ 86.145] (II) Initializing extension XFree86-DRI
[ 86.145] (II) Initializing extension DRI2
[ 86.146] (II) modeset(G0): Damage tracking initialized
[ 86.146] (II) modeset(0): Damage tracking initialized
[ 86.204] (II) config/udev: Adding input device pwr_button (/dev/input/event0)
[ 86.204] (**) pwr_button: Applying InputClass "libinput keyboard catchall"
[ 86.204] (II) Using input driver 'libinput' for 'pwr_button'
[ 86.204] (**) pwr_button: always reports core events
[ 86.204] (**) Option "Device" "/dev/input/event0"
[ 86.204] (**) Option "_source" "server/udev"
[ 86.206] (II) event0 - pwr_button: is tagged by udev as: Keyboard
[ 86.206] (II) event0 - pwr_button: device is a keyboard
[ 86.206] (II) event0 - pwr_button: device removed
[ 86.232] (**) Option "config_info" "udev:/sys/devices/platform/pwr_button/input/input0/event0"
[ 86.232] (**) Option "xkb_model" "pc105"
[ 86.232] (**) Option "xkb_layout" "us"
[ 86.233] (II) event0 - pwr_button: is tagged by udev as: Keyboard
[ 86.233] (II) event0 - pwr_button: device is a keyboard
[ 86.233] (II) config/udev: Adding input device vc4-hdmi-0 (/dev/input/event1)
[ 86.233] (**) vc4-hdmi-0: Applying InputClass "libinput keyboard catchall"
[ 86.233] (II) Using input driver 'libinput' for 'vc4-hdmi-0'
[ 86.233] (**) vc4-hdmi-0: always reports core events
[ 86.233] (**) Option "Device" "/dev/input/event1"
[ 86.233] (**) Option "_source" "server/udev"
[ 86.235] (II) event1 - vc4-hdmi-0: is tagged by udev as: Keyboard Pointingstick
[ 86.235] (II) event1 - vc4-hdmi-0: device is a pointer
[ 86.235] (II) event1 - vc4-hdmi-0: device is a keyboard
[ 86.235] (II) event1 - vc4-hdmi-0: device removed
[ 86.272] (II) libinput: vc4-hdmi-0: needs a virtual subdevice
[ 86.272] (**) Option "config_info" "udev:/sys/devices/platform/soc/107c701400.hdmi/rc/rc0/input1/event1"
[ 86.272] (**) Option "AccelerationScheme" "none"
[ 86.272] (**) vc4-hdmi-0: (accel) selected scheme none/0
[ 86.272] (**) vc4-hdmi-0: (accel) acceleration factor: 2.000
[ 86.272] (**) vc4-hdmi-0: (accel) acceleration threshold: 4
[ 86.273] (II) event1 - vc4-hdmi-0: is tagged by udev as: Keyboard Pointingstick
[ 86.274] (II) event1 - vc4-hdmi-0: device is a pointer
[ 86.274] (II) event1 - vc4-hdmi-0: device is a keyboard
[ 86.275] (II) config/udev: Adding input device vc4-hdmi-1 (/dev/input/event2)
[ 86.275] (**) vc4-hdmi-1: Applying InputClass "libinput keyboard catchall"
[ 86.275] (II) Using input driver 'libinput' for 'vc4-hdmi-1'
[ 86.275] (**) vc4-hdmi-1: always reports core events
[ 86.275] (**) Option "Device" "/dev/input/event2"
[ 86.275] (**) Option "_source" "server/udev"
[ 86.276] (II) event2 - vc4-hdmi-1: is tagged by udev as: Keyboard Pointingstick
[ 86.276] (II) event2 - vc4-hdmi-1: device is a pointer
[ 86.276] (II) event2 - vc4-hdmi-1: device is a keyboard
[ 86.277] (II) event2 - vc4-hdmi-1: device removed
[ 86.296] (II) libinput: vc4-hdmi-1: needs a virtual subdevice
[ 86.296] (**) Option "config_info" "udev:/sys/devices/platform/soc/107c706400.hdmi/rc/rc1/input2/event2"
[ 86.296] (**) Option "AccelerationScheme" "none"
[ 86.296] (**) vc4-hdmi-1: (accel) selected scheme none/0
[ 86.296] (**) vc4-hdmi-1: (accel) acceleration factor: 2.000
[ 86.296] (**) vc4-hdmi-1: (accel) acceleration threshold: 4
[ 86.297] (II) event2 - vc4-hdmi-1: is tagged by udev as: Keyboard Pointingstick
[ 86.298] (II) event2 - vc4-hdmi-1: device is a pointer
[ 86.298] (II) event2 - vc4-hdmi-1: device is a keyboard
[ 86.304] (**) vc4-hdmi-0: Applying InputClass "libinput keyboard catchall"
[ 86.304] (II) Using input driver 'libinput' for 'vc4-hdmi-0'
[ 86.304] (**) vc4-hdmi-0: always reports core events
[ 86.304] (**) Option "Device" "/dev/input/event1"
[ 86.304] (**) Option "_source" "_driver/libinput"
[ 86.304] (II) libinput: vc4-hdmi-0: is a virtual subdevice
[ 86.304] (**) Option "config_info" "udev:/sys/devices/platform/soc/107c701400.hdmi/rc/rc0/input1/event1"
[ 86.304] (**) Option "xkb_model" "pc105"
[ 86.304] (**) Option "xkb_layout" "us"
[ 86.304] (**) vc4-hdmi-1: Applying InputClass "libinput keyboard catchall"
[ 86.304] (II) Using input driver 'libinput' for 'vc4-hdmi-1'
[ 86.304] (**) vc4-hdmi-1: always reports core events
[ 86.304] (**) Option "Device" "/dev/input/event2"
[ 86.304] (**) Option "_source" "_driver/libinput"
[ 86.304] (II) libinput: vc4-hdmi-1: is a virtual subdevice
[ 86.304] (**) Option "config_info" "udev:/sys/devices/platform/soc/107c706400.hdmi/rc/rc1/input2/event2"
[ 86.304] (**) Option "xkb_model" "pc105"
[ 86.304] (**) Option "xkb_layout" "us"
I confirm that with patched driver it works.
But I have removed the configuration in file /etc/X11/xorg.conf.d/99-vc4.conf to view the plugin touch display output, otherwise I got black screen. (my config is rpi5+ dsi waveshare display 11.9)
I’m still fighting with touchscreen rotation and configuration.
After @danidemo’s finding could you post another xorg log after removing “/etc/X11/xorg.conf.d/99-vc4.conf” and restarting the Touch Display plugin, please?
if I remove the file “/etc/X11/xorg.conf.d/99-vc4.conf” the display works also when I enable the touch-display plugin
here the log
[ 44.133]
X.Org X Server 1.20.4
X Protocol Version 11, Revision 0
[ 44.133] Build Operating System: Linux 5.4.0-109-generic armv8l Raspbian
[ 44.133] Current Operating System: Linux volumio-usb 6.1.69-v8+ #1710 SMP PREEMPT Thu Dec 21 13:21:40 GMT 2023 aarch64
[ 44.133] Kernel command line: reboot=w coherent_pool=1M 8250.nr_uarts=1 pci=pcie_bus_safe snd_bcm2835.enable_compat_alsa=0 snd_bcm2835.enable_hdmi=1 smsc95xx.macaddr=D8:3A:DD:7B:C6:00 vc_mem.mem_base=0x3fc00000 vc_mem.mem_size=0x40000000 splash plymouth.ignore-serial-consoles dwc_otg.fiq_enable=1 dwc_otg.fiq_fsm_enable=1 dwc_otg.fiq_fsm_mask=0xF dwc_otg.nak_holdoff=1 quiet console=ttyAMA0,115200 console=tty1 imgpart=UUID=09e9eb41-a375-4504-bd95-b9fb31bf869c imgfile=/volumio_current.sqsh bootpart=UUID=1580-EA53 datapart=UUID=5f69cd19-e2eb-4159-a4fb-faef243916c3 bootconfig=cmdline.txt pcie_aspm=off pci=pcie_bus_safe bootdelay=5 logo.nologo vt.global_cursor_default=0 net.ifnames=0 snd-bcm2835.enable_compat_alsa= snd_bcm2835.enable_hdmi=1 snd_bcm2835.enable_headphones=1 loglevel=0
[ 44.133] Build Date: 04 April 2023 07:50:56AM
[ 44.133] xorg-server 2:1.20.4-1+rpt4+deb10u9 (https://www.debian.org/support)
[ 44.133] Current version of pixman: 0.36.0
[ 44.133] Before reporting problems, check http://wiki.x.org
to make sure that you have the latest version.
[ 44.133] Markers: (--) probed, (**) from config file, (==) default setting,
(++) from command line, (!!) notice, (II) informational,
(WW) warning, (EE) error, (NI) not implemented, (??) unknown.
[ 44.133] (==) Log file: "/var/log/Xorg.0.log", Time: Thu Feb 15 14:43:59 2024
[ 44.162] (==) Using config directory: "/etc/X11/xorg.conf.d"
[ 44.162] (==) Using system config directory "/usr/share/X11/xorg.conf.d"
[ 44.215] (==) No Layout section. Using the first Screen section.
[ 44.215] (==) No screen section available. Using defaults.
[ 44.215] (**) |-->Screen "Default Screen Section" (0)
[ 44.215] (**) | |-->Monitor "<default monitor>"
[ 44.221] (==) No monitor specified for screen "Default Screen Section".
Using a default monitor configuration.
[ 44.221] (==) Automatically adding devices
[ 44.221] (==) Automatically enabling devices
[ 44.221] (==) Automatically adding GPU devices
[ 44.221] (==) Max clients allowed: 256, resource mask: 0x1fffff
[ 44.236] (WW) The directory "/usr/share/fonts/X11/cyrillic" does not exist.
[ 44.236] Entry deleted from font path.
[ 44.262] (==) FontPath set to:
/usr/share/fonts/X11/misc,
/usr/share/fonts/X11/100dpi/:unscaled,
/usr/share/fonts/X11/75dpi/:unscaled,
/usr/share/fonts/X11/Type1,
/usr/share/fonts/X11/100dpi,
/usr/share/fonts/X11/75dpi,
built-ins
[ 44.262] (==) ModulePath set to "/usr/lib/xorg/modules"
[ 44.262] (II) The server relies on udev to provide the list of input devices.
If no devices become available, reconfigure udev or disable AutoAddDevices.
[ 44.262] (II) Loader magic: 0x1fdf80
[ 44.262] (II) Module ABI versions:
[ 44.262] X.Org ANSI C Emulation: 0.4
[ 44.262] X.Org Video Driver: 24.0
[ 44.262] X.Org XInput driver : 24.1
[ 44.262] X.Org Server Extension : 10.0
[ 44.262] (--) using VT number 2
[ 44.262] (II) systemd-logind: logind integration requires -keeptty and -keeptty was not provided, disabling logind integration
[ 44.264] (II) xfree86: Adding drm device (/dev/dri/card1)
[ 44.267] (II) xfree86: Adding drm device (/dev/dri/card0)
[ 44.267] (II) xfree86: Adding drm device (/dev/dri/card2)
[ 44.268] (II) no primary bus or device found
[ 44.268] falling back to /sys/devices/platform/axi/1000120000.pcie/1f00130000.dsi/drm/card1
[ 44.268] (II) LoadModule: "glx"
[ 44.286] (II) Loading /usr/lib/xorg/modules/extensions/libglx.so
[ 44.429] (II) Module glx: vendor="X.Org Foundation"
[ 44.429] compiled for 1.20.4, module version = 1.0.0
[ 44.429] ABI class: X.Org Server Extension, version 10.0
[ 44.429] (==) Matched modesetting as autoconfigured driver 0
[ 44.429] (==) Matched fbdev as autoconfigured driver 1
[ 44.429] (==) Assigned the driver to the xf86ConfigLayout
[ 44.429] (II) LoadModule: "modesetting"
[ 44.445] (II) Loading /usr/lib/xorg/modules/drivers/modesetting_drv.so
[ 44.468] (II) Module modesetting: vendor="X.Org Foundation"
[ 44.468] compiled for 1.20.4, module version = 1.20.4
[ 44.468] Module class: X.Org Video Driver
[ 44.468] ABI class: X.Org Video Driver, version 24.0
[ 44.468] (II) LoadModule: "fbdev"
[ 44.468] (II) Loading /usr/lib/xorg/modules/drivers/fbdev_drv.so
[ 44.487] (II) Module fbdev: vendor="X.Org Foundation"
[ 44.487] compiled for 1.20.3, module version = 0.5.0
[ 44.487] Module class: X.Org Video Driver
[ 44.487] ABI class: X.Org Video Driver, version 24.0
[ 44.487] (II) modesetting: Driver for Modesetting Kernel Drivers: kms
[ 44.487] (II) FBDEV: driver for framebuffer: fbdev
[ 44.516] (II) modeset(0): using drv /dev/dri/card1
[ 44.516] (WW) Falling back to old probe method for fbdev
[ 44.516] (II) Loading sub module "fbdevhw"
[ 44.516] (II) LoadModule: "fbdevhw"
[ 44.516] (II) Loading /usr/lib/xorg/modules/libfbdevhw.so
[ 44.566] (II) Module fbdevhw: vendor="X.Org Foundation"
[ 44.566] compiled for 1.20.4, module version = 0.0.2
[ 44.566] ABI class: X.Org Video Driver, version 24.0
[ 44.566] (II) modeset(G0): using drv /dev/dri/card2
[ 44.567] (II) modeset(0): Creating default Display subsection in Screen section
"Default Screen Section" for depth/fbbpp 24/32
[ 44.567] (==) modeset(0): Depth 24, (==) framebuffer bpp 32
[ 44.567] (==) modeset(0): RGB weight 888
[ 44.567] (==) modeset(0): Default visual is TrueColor
[ 44.567] (II) Loading sub module "glamoregl"
[ 44.567] (II) LoadModule: "glamoregl"
[ 44.567] (II) Loading /usr/lib/xorg/modules/libglamoregl.so
[ 44.658] (II) Module glamoregl: vendor="X.Org Foundation"
[ 44.658] compiled for 1.20.4, module version = 1.0.1
[ 44.658] ABI class: X.Org ANSI C Emulation, version 0.4
[ 45.893] (II) modeset(0): Refusing to try glamor on llvmpipe
[ 45.894] (EE) modeset(0): glamor initialization failed
[ 45.894] (II) modeset(0): ShadowFB: preferred NO, enabled NO
[ 45.895] (II) modeset(0): Output DSI-2 has no monitor section
[ 45.895] (II) modeset(0): EDID for output DSI-2
[ 45.895] (II) modeset(0): Printing probed modes for output DSI-2
[ 45.895] (II) modeset(0): Modeline "320x1480"x60.2 50.00 320 380 440 500 1480 1540 1600 1660 (100.0 kHz eP)
[ 45.895] (II) modeset(0): Output DSI-2 connected
[ 45.895] (II) modeset(0): Using exact sizes for initial modes
[ 45.895] (II) modeset(0): Output DSI-2 using initial mode 320x1480 +0+0
[ 45.895] (==) modeset(0): Using gamma correction (1.0, 1.0, 1.0)
[ 45.895] (==) modeset(0): DPI set to (96, 96)
[ 45.895] (II) Loading sub module "fb"
[ 45.895] (II) LoadModule: "fb"
[ 45.895] (II) Loading /usr/lib/xorg/modules/libfb.so
[ 45.900] (II) Module fb: vendor="X.Org Foundation"
[ 45.900] compiled for 1.20.4, module version = 1.0.0
[ 45.900] ABI class: X.Org ANSI C Emulation, version 0.4
[ 45.900] (==) modeset(G0): Depth 24, (==) framebuffer bpp 32
[ 45.900] (==) modeset(G0): RGB weight 888
[ 45.900] (==) modeset(G0): Default visual is TrueColor
[ 45.900] (II) Loading sub module "glamoregl"
[ 45.900] (II) LoadModule: "glamoregl"
[ 45.900] (II) Loading /usr/lib/xorg/modules/libglamoregl.so
[ 45.900] (II) Module glamoregl: vendor="X.Org Foundation"
[ 45.900] compiled for 1.20.4, module version = 1.0.1
[ 45.900] ABI class: X.Org ANSI C Emulation, version 0.4
[ 46.285] (II) modeset(G0): Refusing to try glamor on llvmpipe
[ 46.286] (EE) modeset(G0): glamor initialization failed
[ 46.286] (II) modeset(G0): ShadowFB: preferred NO, enabled NO
[ 46.292] (II) modeset(G0): Output HDMI-1-1 has no monitor section
[ 46.294] (II) modeset(G0): Output HDMI-1-2 has no monitor section
[ 46.296] (II) modeset(G0): EDID for output HDMI-1-1
[ 46.298] (II) modeset(G0): EDID for output HDMI-1-2
[ 46.298] (==) modeset(G0): Using gamma correction (1.0, 1.0, 1.0)
[ 46.298] (==) modeset(G0): DPI set to (96, 96)
[ 46.298] (II) Loading sub module "fb"
[ 46.298] (II) LoadModule: "fb"
[ 46.298] (II) Loading /usr/lib/xorg/modules/libfb.so
[ 46.298] (II) Module fb: vendor="X.Org Foundation"
[ 46.298] compiled for 1.20.4, module version = 1.0.0
[ 46.298] ABI class: X.Org ANSI C Emulation, version 0.4
[ 46.298] (II) UnloadModule: "fbdev"
[ 46.298] (II) Unloading fbdev
[ 46.298] (II) UnloadSubModule: "fbdevhw"
[ 46.298] (II) Unloading fbdevhw
[ 46.318] (==) modeset(G0): Backing store enabled
[ 46.318] (==) modeset(G0): Silken mouse enabled
[ 46.327] (II) modeset(G0): Initializing kms color map for depth 24, 8 bpc.
[ 46.327] (==) modeset(G0): DPMS enabled
[ 46.327] (==) modeset(0): Backing store enabled
[ 46.327] (==) modeset(0): Silken mouse enabled
[ 46.342] (II) modeset(0): Initializing kms color map for depth 24, 8 bpc.
[ 46.342] (==) modeset(0): DPMS enabled
[ 46.342] (II) Initializing extension Generic Event Extension
[ 46.343] (II) Initializing extension SHAPE
[ 46.343] (II) Initializing extension MIT-SHM
[ 46.343] (II) Initializing extension XInputExtension
[ 46.347] (II) Initializing extension XTEST
[ 46.347] (II) Initializing extension BIG-REQUESTS
[ 46.348] (II) Initializing extension SYNC
[ 46.348] (II) Initializing extension XKEYBOARD
[ 46.348] (II) Initializing extension XC-MISC
[ 46.349] (II) Initializing extension SECURITY
[ 46.349] (II) Initializing extension XFIXES
[ 46.349] (II) Initializing extension RENDER
[ 46.350] (II) Initializing extension RANDR
[ 46.350] (II) Initializing extension COMPOSITE
[ 46.351] (II) Initializing extension DAMAGE
[ 46.351] (II) Initializing extension MIT-SCREEN-SAVER
[ 46.351] (II) Initializing extension DOUBLE-BUFFER
[ 46.352] (II) Initializing extension RECORD
[ 46.352] (II) Initializing extension DPMS
[ 46.352] (II) Initializing extension Present
[ 46.353] (II) Initializing extension DRI3
[ 46.353] (II) Initializing extension X-Resource
[ 46.353] (II) Initializing extension XVideo
[ 46.354] (II) Initializing extension XVideo-MotionCompensation
[ 46.354] (II) Initializing extension SELinux
[ 46.354] (II) SELinux: Disabled on system
[ 46.354] (II) Initializing extension GLX
[ 46.354] (II) AIGLX: Screen 0 is not DRI2 capable
[ 46.406] (II) IGLX: Loaded and initialized swrast
[ 46.406] (II) GLX: Initialized DRISWRAST GL provider for screen 0
[ 46.406] (II) Initializing extension XFree86-VidModeExtension
[ 46.406] (II) Initializing extension XFree86-DGA
[ 46.406] (II) Initializing extension XFree86-DRI
[ 46.409] (II) Initializing extension DRI2
[ 46.409] (II) modeset(G0): Damage tracking initialized
[ 46.410] (II) modeset(0): Damage tracking initialized
[ 46.410] (II) modeset(0): Setting screen physical size to 84 x 391
[ 46.528] (II) config/udev: Adding input device 4-0014 Goodix Capacitive TouchScreen (/dev/input/event3)
[ 46.528] (**) 4-0014 Goodix Capacitive TouchScreen: Applying InputClass "libinput keyboard catchall"
[ 46.528] (**) 4-0014 Goodix Capacitive TouchScreen: Applying InputClass "libinput touchscreen catchall"
[ 46.528] (**) 4-0014 Goodix Capacitive TouchScreen: Applying InputClass "Touch rotation"
[ 46.528] (II) LoadModule: "libinput"
[ 46.528] (II) Loading /usr/lib/xorg/modules/input/libinput_drv.so
[ 46.549] (II) Module libinput: vendor="X.Org Foundation"
[ 46.549] compiled for 1.20.3, module version = 0.28.2
[ 46.549] Module class: X.Org XInput Driver
[ 46.549] ABI class: X.Org XInput driver, version 24.1
[ 46.549] (II) Using input driver 'libinput' for '4-0014 Goodix Capacitive TouchScreen'
[ 46.549] (**) 4-0014 Goodix Capacitive TouchScreen: always reports core events
[ 46.549] (**) Option "Device" "/dev/input/event3"
[ 46.549] (**) Option "_source" "server/udev"
[ 46.571] (II) event3 - 4-0014 Goodix Capacitive TouchScreen: is tagged by udev as: Keyboard Touchscreen
[ 46.571] (II) event3 - 4-0014 Goodix Capacitive TouchScreen: device is a keyboard
[ 46.571] (II) event3 - 4-0014 Goodix Capacitive TouchScreen: device is a touch device
[ 46.572] (II) event3 - 4-0014 Goodix Capacitive TouchScreen: device removed
[ 46.588] (II) libinput: 4-0014 Goodix Capacitive TouchScreen: needs a virtual subdevice
[ 46.588] (**) Option "config_info" "udev:/sys/devices/platform/axi/1000120000.pcie/1f00080000.i2c/i2c-4/4-0014/input/input3/event3"
[ 46.588] (II) XINPUT: Adding extended input device "4-0014 Goodix Capacitive TouchScreen" (type: TOUCHSCREEN, id 6)
[ 46.588] (**) Option "AccelerationScheme" "none"
[ 46.588] (**) 4-0014 Goodix Capacitive TouchScreen: (accel) selected scheme none/0
[ 46.588] (**) 4-0014 Goodix Capacitive TouchScreen: (accel) acceleration factor: 2.000
[ 46.588] (**) 4-0014 Goodix Capacitive TouchScreen: (accel) acceleration threshold: 4
[ 46.590] (II) event3 - 4-0014 Goodix Capacitive TouchScreen: is tagged by udev as: Keyboard Touchscreen
[ 46.591] (II) event3 - 4-0014 Goodix Capacitive TouchScreen: device is a keyboard
[ 46.591] (II) event3 - 4-0014 Goodix Capacitive TouchScreen: device is a touch device
[ 46.592] (II) config/udev: Adding input device 4-0014 Goodix Capacitive TouchScreen (/dev/input/mouse0)
[ 46.592] (II) No input driver specified, ignoring this device.
[ 46.592] (II) This device may have been added with another device file.
[ 46.594] (II) config/udev: Adding input device pwr_button (/dev/input/event0)
[ 46.594] (**) pwr_button: Applying InputClass "libinput keyboard catchall"
[ 46.594] (II) Using input driver 'libinput' for 'pwr_button'
[ 46.594] (**) pwr_button: always reports core events
[ 46.594] (**) Option "Device" "/dev/input/event0"
[ 46.594] (**) Option "_source" "server/udev"
[ 46.595] (II) event0 - pwr_button: is tagged by udev as: Keyboard
[ 46.595] (II) event0 - pwr_button: device is a keyboard
[ 46.595] (II) event0 - pwr_button: device removed
[ 46.632] (**) Option "config_info" "udev:/sys/devices/platform/pwr_button/input/input0/event0"
[ 46.632] (II) XINPUT: Adding extended input device "pwr_button" (type: KEYBOARD, id 7)
[ 46.632] (**) Option "xkb_model" "pc105"
[ 46.632] (**) Option "xkb_layout" "us"
[ 46.633] (II) event0 - pwr_button: is tagged by udev as: Keyboard
[ 46.633] (II) event0 - pwr_button: device is a keyboard
[ 46.634] (II) config/udev: Adding input device vc4-hdmi-0 (/dev/input/event1)
[ 46.634] (**) vc4-hdmi-0: Applying InputClass "libinput keyboard catchall"
[ 46.634] (II) Using input driver 'libinput' for 'vc4-hdmi-0'
[ 46.634] (**) vc4-hdmi-0: always reports core events
[ 46.634] (**) Option "Device" "/dev/input/event1"
[ 46.634] (**) Option "_source" "server/udev"
[ 46.636] (II) event1 - vc4-hdmi-0: is tagged by udev as: Keyboard Pointingstick
[ 46.637] (II) event1 - vc4-hdmi-0: device is a pointer
[ 46.637] (II) event1 - vc4-hdmi-0: device is a keyboard
[ 46.637] (II) event1 - vc4-hdmi-0: device removed
[ 46.676] (II) libinput: vc4-hdmi-0: needs a virtual subdevice
[ 46.676] (**) Option "config_info" "udev:/sys/devices/platform/soc/107c701400.hdmi/rc/rc0/input1/event1"
[ 46.676] (II) XINPUT: Adding extended input device "vc4-hdmi-0" (type: MOUSE, id 8)
[ 46.676] (**) Option "AccelerationScheme" "none"
[ 46.676] (**) vc4-hdmi-0: (accel) selected scheme none/0
[ 46.676] (**) vc4-hdmi-0: (accel) acceleration factor: 2.000
[ 46.676] (**) vc4-hdmi-0: (accel) acceleration threshold: 4
[ 46.678] (II) event1 - vc4-hdmi-0: is tagged by udev as: Keyboard Pointingstick
[ 46.678] (II) event1 - vc4-hdmi-0: device is a pointer
[ 46.678] (II) event1 - vc4-hdmi-0: device is a keyboard
[ 46.680] (II) config/udev: Adding input device vc4-hdmi-1 (/dev/input/event2)
[ 46.680] (**) vc4-hdmi-1: Applying InputClass "libinput keyboard catchall"
[ 46.680] (II) Using input driver 'libinput' for 'vc4-hdmi-1'
[ 46.680] (**) vc4-hdmi-1: always reports core events
[ 46.680] (**) Option "Device" "/dev/input/event2"
[ 46.680] (**) Option "_source" "server/udev"
[ 46.682] (II) event2 - vc4-hdmi-1: is tagged by udev as: Keyboard Pointingstick
[ 46.682] (II) event2 - vc4-hdmi-1: device is a pointer
[ 46.682] (II) event2 - vc4-hdmi-1: device is a keyboard
[ 46.683] (II) event2 - vc4-hdmi-1: device removed
[ 46.708] (II) libinput: vc4-hdmi-1: needs a virtual subdevice
[ 46.708] (**) Option "config_info" "udev:/sys/devices/platform/soc/107c706400.hdmi/rc/rc1/input2/event2"
[ 46.708] (II) XINPUT: Adding extended input device "vc4-hdmi-1" (type: MOUSE, id 9)
[ 46.708] (**) Option "AccelerationScheme" "none"
[ 46.708] (**) vc4-hdmi-1: (accel) selected scheme none/0
[ 46.708] (**) vc4-hdmi-1: (accel) acceleration factor: 2.000
[ 46.708] (**) vc4-hdmi-1: (accel) acceleration threshold: 4
[ 46.710] (II) event2 - vc4-hdmi-1: is tagged by udev as: Keyboard Pointingstick
[ 46.710] (II) event2 - vc4-hdmi-1: device is a pointer
[ 46.710] (II) event2 - vc4-hdmi-1: device is a keyboard
[ 46.724] (**) 4-0014 Goodix Capacitive TouchScreen: Applying InputClass "libinput keyboard catchall"
[ 46.724] (**) 4-0014 Goodix Capacitive TouchScreen: Applying InputClass "libinput touchscreen catchall"
[ 46.724] (**) 4-0014 Goodix Capacitive TouchScreen: Applying InputClass "Touch rotation"
[ 46.724] (II) Using input driver 'libinput' for '4-0014 Goodix Capacitive TouchScreen'
[ 46.724] (**) 4-0014 Goodix Capacitive TouchScreen: always reports core events
[ 46.724] (**) Option "Device" "/dev/input/event3"
[ 46.724] (**) Option "_source" "_driver/libinput"
[ 46.724] (II) libinput: 4-0014 Goodix Capacitive TouchScreen: is a virtual subdevice
[ 46.724] (**) Option "config_info" "udev:/sys/devices/platform/axi/1000120000.pcie/1f00080000.i2c/i2c-4/4-0014/input/input3/event3"
[ 46.724] (II) XINPUT: Adding extended input device "4-0014 Goodix Capacitive TouchScreen" (type: KEYBOARD, id 10)
[ 46.724] (**) Option "xkb_model" "pc105"
[ 46.724] (**) Option "xkb_layout" "us"
[ 46.725] (**) vc4-hdmi-0: Applying InputClass "libinput keyboard catchall"
[ 46.725] (II) Using input driver 'libinput' for 'vc4-hdmi-0'
[ 46.725] (**) vc4-hdmi-0: always reports core events
[ 46.725] (**) Option "Device" "/dev/input/event1"
[ 46.725] (**) Option "_source" "_driver/libinput"
[ 46.725] (II) libinput: vc4-hdmi-0: is a virtual subdevice
[ 46.725] (**) Option "config_info" "udev:/sys/devices/platform/soc/107c701400.hdmi/rc/rc0/input1/event1"
[ 46.725] (II) XINPUT: Adding extended input device "vc4-hdmi-0" (type: KEYBOARD, id 11)
[ 46.725] (**) Option "xkb_model" "pc105"
[ 46.725] (**) Option "xkb_layout" "us"
[ 46.725] (**) vc4-hdmi-1: Applying InputClass "libinput keyboard catchall"
[ 46.725] (II) Using input driver 'libinput' for 'vc4-hdmi-1'
[ 46.725] (**) vc4-hdmi-1: always reports core events
[ 46.725] (**) Option "Device" "/dev/input/event2"
[ 46.725] (**) Option "_source" "_driver/libinput"
[ 46.725] (II) libinput: vc4-hdmi-1: is a virtual subdevice
[ 46.725] (**) Option "config_info" "udev:/sys/devices/platform/soc/107c706400.hdmi/rc/rc1/input2/event2"
[ 46.725] (II) XINPUT: Adding extended input device "vc4-hdmi-1" (type: KEYBOARD, id 12)
[ 46.725] (**) Option "xkb_model" "pc105"
[ 46.725] (**) Option "xkb_layout" "us"
[ 47.783] (II) modeset(0): Disabling kernel dirty updates, not required.
[ 47.920] (II) modeset(0): Allocate new frame buffer 1480x320 stride
[ 88.810] (II) Axis 0x35 value 1684 is outside expected range [-15, 334]
See https://wayland.freedesktop.org/libinput/doc/1.12.6/absolute_coordinate_ranges.html for details
for rotating the display, I’ve added this to /home/volumio/.config/openbox/autostart
xrandr --output DSI-2 --rotate left
here it is
volumio@volumio-usb:~$ ls /dev/dri/by-path
platform-1002000000.v3d-card platform-1002000000.v3d-render platform-1f00130000.dsi-card platform-axi:gpu-card
Please try changing Identifier and MatchDriver in “99-vc4.conf” like this:
Section "OutputClass"
Identifier "rp1"
MatchDriver "rp1-vec|rp1-dsi|rp1-dpi"
Driver "modesetting"
Option "PrimaryGPU" "true"
EndSection
it works!
So I think this combined version of “99-vc4.conf” should work, too:
Section "OutputClass"
Identifier "vc4"
MatchDriver "vc4"
Driver "modesetting"
Option "PrimaryGPU" "true"
EndSection
Section "OutputClass"
Identifier "rp1"
MatchDriver "rp1-vec|rp1-dsi|rp1-dpi"
Driver "modesetting"
Option "PrimaryGPU" "true"
EndSection
Could you do another test, please?
sure!
unfortunately it doesn’t work, blank screen again
volumio@volumio-nvme:~$ cat /etc/X11/xorg.conf.d/99-vc4.conf
Section "OutputClass"
Identifier "vc4"
MatchDriver "vc4"
Driver "modesetting"
Option "PrimaryGPU" "true"
EndSection
Section "OutputClass"
Identifier "rp1"
MatchDriver "rp1-vec|rp1-dsi|rp1-dpi"
Driver "modesetting"
Option "PrimaryGPU" "true"
EndSection
volumio@volumio-nvme:~$
Too bad…
Could you try if changing the order of the two OutputClass sections helps?
I would also be interested in the output of
cat /proc/modules
even inverting the order, it doesn’t work… blank screen after reboot
volumio@volumio-nvme:~$ cat /etc/X11/xorg.conf.d/99-vc4.conf
Section "OutputClass"
Identifier "rp1"
MatchDriver "rp1-vec|rp1-dsi|rp1-dpi"
Driver "modesetting"
Option "PrimaryGPU" "true"
EndSection
Section "OutputClass"
Identifier "vc4"
MatchDriver "vc4"
Driver "modesetting"
Option "PrimaryGPU" "true"
EndSection
volumio@volumio-nvme:~$
removing the section with identifier vc4, the display works again (after reboot of course)
here the output you requested (obtained with two sections on 99-vc4.conf, in the order reported above)
volumio@volumio-nvme:~$ cat /proc/modules
nft_chain_nat 16384 4 - Live 0x0000000000000000
bnep 24576 2 - Live 0x0000000000000000
xt_REDIRECT 16384 1 - Live 0x0000000000000000
nf_nat 49152 2 nft_chain_nat,xt_REDIRECT, Live 0x0000000000000000
nf_conntrack 147456 2 xt_REDIRECT,nf_nat, Live 0x0000000000000000
nf_defrag_ipv6 20480 1 nf_conntrack, Live 0x0000000000000000
nf_defrag_ipv4 16384 1 nf_conntrack, Live 0x0000000000000000
xt_tcpudp 16384 1 - Live 0x0000000000000000
nft_compat 20480 2 - Live 0x0000000000000000
nf_tables 249856 5 nft_chain_nat,nft_compat, Live 0x0000000000000000
nfnetlink 20480 2 nft_compat,nf_tables, Live 0x0000000000000000
8021q 32768 0 - Live 0x0000000000000000
garp 16384 1 8021q, Live 0x0000000000000000
stp 16384 1 garp, Live 0x0000000000000000
llc 16384 2 garp,stp, Live 0x0000000000000000
joydev 28672 0 - Live 0x0000000000000000
brcmfmac 327680 0 - Live 0x0000000000000000
panel_waveshare_dsi 16384 0 - Live 0x0000000000000000
spidev 20480 0 - Live 0x0000000000000000
goodix_ts 28672 0 - Live 0x0000000000000000
brcmutil 24576 1 brcmfmac, Live 0x0000000000000000
cfg80211 929792 1 brcmfmac, Live 0x0000000000000000
hci_uart 53248 0 - Live 0x0000000000000000
btbcm 24576 1 hci_uart, Live 0x0000000000000000
bluetooth 565248 24 bnep,hci_uart,btbcm, Live 0x0000000000000000
aes_ce_blk 32768 1 - Live 0x0000000000000000
aes_ce_cipher 16384 1 aes_ce_blk, Live 0x0000000000000000
ghash_ce 20480 0 - Live 0x0000000000000000
gf128mul 16384 1 ghash_ce, Live 0x0000000000000000
ecdh_generic 16384 2 bluetooth, Live 0x0000000000000000
sha2_ce 16384 0 - Live 0x0000000000000000
ecc 36864 1 ecdh_generic, Live 0x0000000000000000
sha256_arm64 24576 1 sha2_ce, Live 0x0000000000000000
rfkill 32768 6 cfg80211,bluetooth, Live 0x0000000000000000
snd_soc_rpi_simple_soundcard 20480 1 - Live 0x0000000000000000
sha1_ce 16384 0 - Live 0x0000000000000000
libaes 16384 4 bluetooth,aes_ce_blk,aes_ce_cipher,ghash_ce, Live 0x0000000000000000
vc4 372736 7 - Live 0x0000000000000000
raspberrypi_hwmon 16384 0 - Live 0x0000000000000000
v3d 90112 0 - Live 0x0000000000000000
rpivid_hevc 53248 0 - Live 0x0000000000000000 (C)
snd_soc_hdmi_codec 20480 2 - Live 0x0000000000000000
pisp_be 32768 0 - Live 0x0000000000000000
drm_display_helper 16384 1 vc4, Live 0x0000000000000000
v4l2_mem2mem 45056 1 rpivid_hevc, Live 0x0000000000000000
gpu_sched 49152 1 v3d, Live 0x0000000000000000
videobuf2_dma_contig 20480 2 rpivid_hevc,pisp_be, Live 0x0000000000000000
cec 53248 1 vc4, Live 0x0000000000000000
designware_i2s 24576 2 - Live 0x0000000000000000
drm_rp1_dsi 20480 1 - Live 0x0000000000000000
snd_soc_pcm1794a 16384 1 - Live 0x0000000000000000
drm_shmem_helper 24576 1 v3d, Live 0x0000000000000000
drm_dma_helper 20480 2 vc4,drm_rp1_dsi, Live 0x0000000000000000
drm_kms_helper 204800 6 vc4,drm_rp1_dsi,drm_dma_helper, Live 0x0000000000000000
snd_soc_core 274432 5 snd_soc_rpi_simple_soundcard,vc4,snd_soc_hdmi_codec,designware_i2s,snd_soc_pcm1794a, Live 0x0000000000000000
videobuf2_memops 16384 1 videobuf2_dma_contig, Live 0x0000000000000000
videobuf2_v4l2 32768 3 rpivid_hevc,pisp_be,v4l2_mem2mem, Live 0x0000000000000000
videobuf2_common 69632 6 rpivid_hevc,pisp_be,v4l2_mem2mem,videobuf2_dma_contig,videobuf2_memops,videobuf2_v4l2, Live 0x0000000000000000
i2c_brcmstb 16384 0 - Live 0x0000000000000000
spi_bcm2835 20480 0 - Live 0x0000000000000000
snd_compress 20480 1 snd_soc_core, Live 0x0000000000000000
snd_pcm_dmaengine 20480 1 snd_soc_core, Live 0x0000000000000000
videodev 274432 5 rpivid_hevc,pisp_be,v4l2_mem2mem,videobuf2_v4l2,videobuf2_common, Live 0x0000000000000000
snd_seq 73728 0 - Live 0x0000000000000000
drm 581632 12 panel_waveshare_dsi,vc4,v3d,drm_display_helper,gpu_sched,drm_rp1_dsi,drm_shmem_helper,drm_dma_helper,drm_kms_helper, Live 0x0000000000000000
snd_pcm 139264 6 snd_soc_rpi_simple_soundcard,snd_soc_hdmi_codec,designware_i2s,snd_soc_core,snd_compress,snd_pcm_dmaengine, Live 0x0000000000000000
snd_seq_device 16384 1 snd_seq, Live 0x0000000000000000
mc 61440 6 rpivid_hevc,pisp_be,v4l2_mem2mem,videobuf2_v4l2,videobuf2_common,videodev, Live 0x0000000000000000
pwm_fan 20480 0 - Live 0x0000000000000000
snd_timer 36864 2 snd_seq,snd_pcm, Live 0x0000000000000000
drm_panel_orientation_quirks 28672 1 drm, Live 0x0000000000000000
fb_sys_fops 16384 1 drm_kms_helper, Live 0x0000000000000000
syscopyarea 16384 1 drm_kms_helper, Live 0x0000000000000000
sysfillrect 16384 1 drm_kms_helper, Live 0x0000000000000000
gpio_keys 20480 0 - Live 0x0000000000000000
sysimgblt 16384 1 drm_kms_helper, Live 0x0000000000000000
snd 106496 13 snd_soc_hdmi_codec,snd_soc_core,snd_compress,snd_seq,snd_pcm,snd_seq_device,snd_timer, Live 0x0000000000000000
backlight 24576 2 panel_waveshare_dsi,drm, Live 0x0000000000000000
raspberrypi_gpiomem 16384 0 - Live 0x0000000000000000
i2c_designware_platform 16384 0 - Live 0x0000000000000000
i2c_designware_core 24576 1 i2c_designware_platform, Live 0x0000000000000000
rp1_adc 16384 0 - Live 0x0000000000000000
uio_pdrv_genirq 16384 0 - Live 0x0000000000000000
uio 24576 1 uio_pdrv_genirq, Live 0x0000000000000000
nvmem_rmem 16384 0 - Live 0x0000000000000000
i2c_dev 20480 0 - Live 0x0000000000000000
ip_tables 32768 0 - Live 0x0000000000000000
x_tables 53248 4 xt_REDIRECT,xt_tcpudp,nft_compat,ip_tables, Live 0x0000000000000000
ipv6 557056 88 [permanent], Live 0x0000000000000000
fuse 135168 1 - Live 0x0000000000000000
squashfs 49152 1 - Live 0x0000000000000000
overlay 126976 1 - Live 0x0000000000000000
