Hi asemev!
Thank you!
I have chosen HIFIBerry DAC 2 HD!
FusionDSP works with Peppy. I have selected DSD native in Alsa Configuration!
I’m using version 3.661
Peppy 2.0
I’m on vacation right now! I can show the configs on Monday!
Thank you so much mchief!
Have a wonderful vacation and very much looking forward to seeing your configs on Monday
Have fun!
Not 2.2?
Sorry 2.1
Not 2.2 yet
Now! 2.2
@asemev
my config.txt
### DO NOT EDIT THIS FILE ###
### APPLY CUSTOM PARAMETERS TO userconfig.txt ###
initramfs volumio.initrd
gpu_mem=128
gpu_mem_256=32
gpu_mem_512=32
gpu_mem_1024=128
max_usb_current=1
[pi5]
usb_max_current_enable=1
[all]
include volumioconfig.txt
include userconfig.txt
#### Volumio i2s setting below: do not alter ####
dtoverlay=hifiberry-dacplushd
my userconfig.txt
# Add your custom config.txt options to this file, which will be preserved during updates
##### 11.9inch Display ####
max_framebuffer_height=1480
hdmi_group=2
hdmi_mode=87
hdmi_timings=320 0 80 16 32 1480 0 16 4 12 0 0 0 60 0 42000000 3
#### Touch Display rotation setting below: do not alter ####
display_lcd_rotate=3
display_hdmi_rotate=3
my volumioconfig.txt
### DO NOT EDIT THIS FILE ###
### APPLY CUSTOM PARAMETERS TO userconfig.txt ###
[cm4]
dtoverlay=dwc2,dr_mode=host
otg_mode=1
[pi5]
dtoverlay=vc4-kms-v3d-pi5
[all]
arm_64bit=0
dtparam=audio=on
audio_pwm_mode=2
dtparam=i2c_arm=on
disable_splash=1
hdmi_force_hotplug=1
force_eeprom_read=0
That works for me
Thanks a million mchief!! Will try it tonight
I hope I was able to help. Reports on your progress
1 Like
Thank you so much again! I made a clean install and used your serttings and everything works most of the time. But Volumio seems to have a lot of bugs. Every now and then when i restart volumio nothing works, like pressing play button on the web interface or volumio app doesnt play at all. Only when i restart again then things work (but still not always). And also when volumio is playing music from the volumio spotify interface, and if i try to play a song from my phone spotify app, then either it doesnt play the song, or it plays the the song but peppymeter doesnt work, and switching vu meters on title change dont work, etc etc. so overall it looks like there are very serious overall stability issues with volumio and these plugins. I will keep tinkering though
Spotify is apparently supposed to cause problems here more often!
I’m not using it
I use Qobuz
What hardware do you use?
Oh I see, ok i didnt know that. Thank you for this info. I’m using almost same HW as you: Rpi4B + Hifiberry DAC 2HD and the smaller Waveshare 7.9 HDMI.
Hi, I love your work, it’s really great and very professional. I would like to achieve the same thing with a waveshare 11.9 screen. I don’t have the gx388 case yet but I would like to know if you would be willing to provide the plan for cutting it out? I would need a .dxf , dwg file for cutting. Schaeffer. THANKS
