cat /boot/config.txtcat /boot/userconfig.txttry adding display_auto_detect=1 to /boot/userconfig.txt if it’s not there yet.
You will probably have to add
dtoverlay=vc4-kms-dsi-7inch
to “/boot/userconfig.txt”.
So for Volumio I am running 3.785. The touch screen is…Freenove 5 / 7 Inch Touchscreen Monitor for Raspberry Pi 5 4 B 3 B+
When I boot the screen does nothing, while the TV displays the Volumio boot logo.
Not sure if I know how to do this.
What is the output of:
cat /boot/config.txt
cat /boot/userconfig.txt
I’ll try this… try adding display_auto_detect=1 to /boot/userconfig.txt
and… dtoverlay=vc4-kms-dsi-7inch
Sigh, now I got nothing on the TV.
cat /boot/config.txt :
initramfs volumio.initrd
gpu_mem=128
gpu_mem_256=32
gpu_mem_512=32
gpu_mem_1024=128
max_usb_current=1
[pi5]
usb_max_current_enable=1
[all]
initramfs volumio.initrd
gpu_mem=128
gpu_mem_256=32
gpu_mem_512=32
gpu_mem_1024=128
max_usb_current=1
[pi5]
usb_max_current_enable=1
[all]
include volumioconfig.txt
include userconfig.txt
display_auto_detect=1
dtoverlay=vc4-kms-dsi-7inch
volumio@volumio:~$
No idea if i did that right…anyway…like I said now the TV display isn’t working. I haven’t tried the 5" yet, I was gonna send it back then I decided to post about it, so I have to hook it back up. I’ll post when I have it hooked back up.
Edit: Well I got the 5" touch screen working, or should I say you guys got it working, but now the TV display does not work. Any chance I can get both working, or am I pushing my luck?
Any way, thanks so much for the help.
According to Freenove you should use the vc4-kms-3d overlay, although that seems strange to me.
There are a couple of other drivers in the /boot/overlays directory that are worth a try
vc4-kms-dsi-generic
vc4-kms-dsi-ili9881-5inch
You can try adding another line to userconfig.txt
dtoverlay=vc4-kms-dsi-7inch
dtoverlay=vc4-kms-v3dI have been trying to get the Touch Display Plugin to install. I am running this on a Raspberry Pi 3B+ and have the Raspberry PI touch display 2.
After updating my boot settings, the login prompt shows on the Touch Display, but when I try to install the plugin I keep getting an error.
I have tried recommendations in several threads here, but nothing has helped.
An error occurred while installing the plugin Error
Downloading plugin at https://plugins.volumio.workers.dev/pluginsv2/downloadLatestStable/touch_display/volumio/buster/armhf
END DOWNLOAD: https://plugins.volumio.workers.dev/pluginsv2/downloadLatestStable/touch_display/volumio/buster/armhf
Creating install location
Unpacking plugin
Checking that the plugin is suitable for this version of Volumio The plugin can be used with this version of Volumio
Checking for duplicate plugin
Copying plugin to location
Installing necessary utilities
Re-synchronizing package index files from their sources
Hit:1 http://raspbian.raspberrypi.org/raspbian buster InRelease
Hit:2 https://deb.nodesource.com/node_14.x buster InRelease
Hit:3 http://archive.raspberrypi.org/debian buster InRelease
Reading package lists...
Reading package lists...
Building dependency tree...
Reading state information...
0 upgraded, 0 newly installed, 0 to remove and 207 not upgraded.
Installing graphical environment
Reading package lists...
Building dependency tree...
Reading state information...
The following additional packages will be installed:
keyboard-configuration libdrm-amdgpu1 libdrm-nouveau2 libdrm-radeon1
libegl-mesa0 libegl1 libegl1-mesa libepoxy0 libevdev2 libfontenc1 libgbm1
libgl1 libgl1-mesa-dri libglapi-mesa libglvnd0 libglx-mesa0 libglx0
libgudev-1.0-0 libinput-bin libinput10 libllvm9 libmtdev1 libpciaccess0
libsensors-config libsensors5 libunwind8 libutempter0 libwacom-bin
libwacom-common libwacom2 libwayland-server0 libxaw7 libxcb-dri2-0
libxcb-dri3-0 libxcb-glx0 libxcb-present0 libxcb-shape0 libxcb-sync1
libxcb-xfixes0 libxcomposite1 libxdamage1 libxfont2 libxft2 libxkbfile1
libxmu6 libxpm4 libxshmfence1 libxt6 libxv1 libxxf86dga1 x11-utils
x11-xkb-utils xbitmaps xfonts-base xfonts-encodings xfonts-utils
xserver-common xserver-xorg xserver-xorg-core xserver-xorg-input-all
xserver-xorg-input-libinput xserver-xorg-input-wacom xserver-xorg-legacy
xserver-xorg-video-all xserver-xorg-video-amdgpu xserver-xorg-video-ati
xserver-xorg-video-fbdev xserver-xorg-video-nouveau
xserver-xorg-video-radeon xserver-xorg-video-vesa xterm
Suggested packages:
pciutils lm-sensors mesa-utils xfonts-100dpi | xfonts-75dpi xfonts-scalable
xinput firmware-amd-graphics xserver-xorg-video-r128
xserver-xorg-video-mach64 xfonts-cyrillic
The following NEW packages will be installed:
keyboard-configuration libdrm-amdgpu1 libdrm-nouveau2 libdrm-radeon1
libegl-mesa0 libegl1 libegl1-mesa libepoxy0 libevdev2 libfontenc1 libgbm1
libgl1 libgl1-mesa-dri libglapi-mesa libglvnd0 libglx-mesa0 libglx0
libgudev-1.0-0 libinput-bin libinput10 libllvm9 libmtdev1 libpciaccess0
libsensors-config libsensors5 libunwind8 libutempter0 libwacom-bin
libwacom-common libwacom2 libwayland-server0 libxaw7 libxcb-dri2-0
libxcb-dri3-0 libxcb-glx0 libxcb-present0 libxcb-shape0 libxcb-sync1
libxcb-xfixes0 libxcomposite1 libxdamage1 libxfont2 libxft2 libxkbfile1
libxmu6 libxpm4 libxshmfence1 libxt6 libxv1 libxxf86dga1 x11-utils
x11-xkb-utils xbitmaps xfonts-base xfonts-encodings xfonts-utils xinit
xserver-common xserver-xorg xserver-xorg-core xserver-xorg-input-all
xserver-xorg-input-libinput xserver-xorg-input-wacom xserver-xorg-legacy
xserver-xorg-video-all xserver-xorg-video-amdgpu xserver-xorg-video-ati
xserver-xorg-video-fbdev xserver-xorg-video-nouveau
xserver-xorg-video-radeon xserver-xorg-video-vesa xterm
0 upgraded, 72 newly installed, 0 to remove and 207 not upgraded.
Need to get 0 B/39.0 MB of archives.
After this operation, 581 MB of additional disk space will be used.
Selecting previously unselected package keyboard-configuration.
(Reading database ... (Reading database ... 5% (Reading database ... 10% (Reading database ... 15% dpkg: warning: files list file for package 'plymouth-themes' missing; assuming package has no files currently installed
dpkg: warning: files list file for package 'libxslt1.1:armhf' missing; assuming package has no files currently installed
(Reading database ... 20% (Reading database ... 25% (Reading database ... 30% (Reading database ... 35% (Reading database ... 40% (Reading database ... 45% (Reading database ... 50% (Reading database ... 55% (Reading database ... 60% (Reading database ... 65% (Reading database ... 70% (Reading database ... 75% (Reading database ... 80% (Reading database ... 85% (Reading database ... 90% (Reading database ... 95% (Reading database ... 100% (Reading database ... 36378 files and directories currently installed.)
Preparing to unpack .../00-keyboard-configuration_1.193~deb10u1_all.deb ...
Unpacking keyboard-configuration (1.193~deb10u1) ...
Selecting previously unselected package libxxf86dga1:armhf.
Preparing to unpack .../01-libxxf86dga1_2%3a1.1.4-1_armhf.deb ...
Unpacking libxxf86dga1:armhf (2:1.1.4-1) ...
Selecting previously unselected package libdrm-amdgpu1:armhf.
Preparing to unpack .../02-libdrm-amdgpu1_2.4.100-4+rpi1~bpo10+1_armhf.deb ...
Unpacking libdrm-amdgpu1:armhf (2.4.100-4+rpi1~bpo10+1) ...
Selecting previously unselected package libdrm-nouveau2:armhf.
Preparing to unpack .../03-libdrm-nouveau2_2.4.100-4+rpi1~bpo10+1_armhf.deb ...
Unpacking libdrm-nouveau2:armhf (2.4.100-4+rpi1~bpo10+1) ...
Selecting previously unselected package libdrm-radeon1:armhf.
Preparing to unpack .../04-libdrm-radeon1_2.4.100-4+rpi1~bpo10+1_armhf.deb ...
Unpacking libdrm-radeon1:armhf (2.4.100-4+rpi1~bpo10+1) ...
Selecting previously unselected package libwayland-server0:armhf.
Preparing to unpack .../05-libwayland-server0_1.16.0-1_armhf.deb ...
Unpacking libwayland-server0:armhf (1.16.0-1) ...
Selecting previously unselected package libgbm1:armhf.
Preparing to unpack .../06-libgbm1_19.3.2-1~bpo10+1~rpt4_armhf.deb ...
Unpacking libgbm1:armhf (19.3.2-1~bpo10+1~rpt4) ...
Selecting previously unselected package libglapi-mesa:armhf.
Preparing to unpack .../07-libglapi-mesa_19.3.2-1~bpo10+1~rpt4_armhf.deb ...
Unpacking libglapi-mesa:armhf (19.3.2-1~bpo10+1~rpt4) ...
Selecting previously unselected package libxcb-dri2-0:armhf.
Preparing to unpack .../08-libxcb-dri2-0_1.13.1-2_armhf.deb ...
Unpacking libxcb-dri2-0:armhf (1.13.1-2) ...
Selecting previously unselected package libxcb-dri3-0:armhf.
Preparing to unpack .../09-libxcb-dri3-0_1.13.1-2_armhf.deb ...
Unpacking libxcb-dri3-0:armhf (1.13.1-2) ...
Selecting previously unselected package libxcb-present0:armhf.
Preparing to unpack .../10-libxcb-present0_1.13.1-2_armhf.deb ...
Unpacking libxcb-present0:armhf (1.13.1-2) ...
Selecting previously unselected package libxcb-sync1:armhf.
Preparing to unpack .../11-libxcb-sync1_1.13.1-2_armhf.deb ...
Unpacking libxcb-sync1:armhf (1.13.1-2) ...
Selecting previously unselected package libxcb-xfixes0:armhf.
Preparing to unpack .../12-libxcb-xfixes0_1.13.1-2_armhf.deb ...
Unpacking libxcb-xfixes0:armhf (1.13.1-2) ...
Selecting previously unselected package libxshmfence1:armhf.
Preparing to unpack .../13-libxshmfence1_1.3-1_armhf.deb ...
Unpacking libxshmfence1:armhf (1.3-1) ...
Selecting previously unselected package libegl-mesa0:armhf.
Preparing to unpack .../14-libegl-mesa0_19.3.2-1~bpo10+1~rpt4_armhf.deb ...
Unpacking libegl-mesa0:armhf (19.3.2-1~bpo10+1~rpt4) ...
Selecting previously unselected package libglvnd0:armhf.
Preparing to unpack .../15-libglvnd0_1.3.0-7~bpo10+1_armhf.deb ...
Unpacking libglvnd0:armhf (1.3.0-7~bpo10+1) ...
Selecting previously unselected package libegl1:armhf.
Preparing to unpack .../16-libegl1_1.3.0-7~bpo10+1_armhf.deb ...
Unpacking libegl1:armhf (1.3.0-7~bpo10+1) ...
Selecting previously unselected package libegl1-mesa:armhf.
Preparing to unpack .../17-libegl1-mesa_19.3.2-1~bpo10+1~rpt4_armhf.deb ...
Unpacking libegl1-mesa:armhf (19.3.2-1~bpo10+1~rpt4) ...
Selecting previously unselected package libepoxy0:armhf.
Preparing to unpack .../18-libepoxy0_1.5.3-0.1_armhf.deb ...
Unpacking libepoxy0:armhf (1.5.3-0.1) ...
Selecting previously unselected package libevdev2:armhf.
Preparing to unpack .../19-libevdev2_1.6.0+dfsg-1_armhf.deb ...
Unpacking libevdev2:armhf (1.6.0+dfsg-1) ...
Selecting previously unselected package libfontenc1:armhf.
Preparing to unpack .../20-libfontenc1_1%3a1.1.3-1_armhf.deb ...
Unpacking libfontenc1:armhf (1:1.1.3-1) ...
Selecting previously unselected package libxcb-glx0:armhf.
Preparing to unpack .../21-libxcb-glx0_1.13.1-2_armhf.deb ...
Unpacking libxcb-glx0:armhf (1.13.1-2) ...
Selecting previously unselected package libxdamage1:armhf.
Preparing to unpack .../22-libxdamage1_1%3a1.1.4-3+b3_armhf.deb ...
Unpacking libxdamage1:armhf (1:1.1.4-3+b3) ...
Selecting previously unselected package libllvm9:armhf.
Preparing to unpack .../23-libllvm9_1%3a9.0.1-6+rpi1~bpo10+1_armhf.deb ...
Unpacking libllvm9:armhf (1:9.0.1-6+rpi1~bpo10+1) ...
Selecting previously unselected package libsensors-config.
Preparing to unpack .../24-libsensors-config_1%3a3.5.0-3_all.deb ...
Unpacking libsensors-config (1:3.5.0-3) ...
Selecting previously unselected package libsensors5:armhf.
Preparing to unpack .../25-libsensors5_1%3a3.5.0-3_armhf.deb ...
Unpacking libsensors5:armhf (1:3.5.0-3) ...
Selecting previously unselected package libgl1-mesa-dri:armhf.
Preparing to unpack .../26-libgl1-mesa-dri_19.3.2-1~bpo10+1~rpt4_armhf.deb ...
Unpacking libgl1-mesa-dri:armhf (19.3.2-1~bpo10+1~rpt4) ...
Selecting previously unselected package libglx-mesa0:armhf.
Preparing to unpack .../27-libglx-mesa0_19.3.2-1~bpo10+1~rpt4_armhf.deb ...
Unpacking libglx-mesa0:armhf (19.3.2-1~bpo10+1~rpt4) ...
Selecting previously unselected package libglx0:armhf.
Preparing to unpack .../28-libglx0_1.3.0-7~bpo10+1_armhf.deb ...
Unpacking libglx0:armhf (1.3.0-7~bpo10+1) ...
Selecting previously unselected package libgl1:armhf.
Preparing to unpack .../29-libgl1_1.3.0-7~bpo10+1_armhf.deb ...
Unpacking libgl1:armhf (1.3.0-7~bpo10+1) ...
Selecting previously unselected package libgudev-1.0-0:armhf.
Preparing to unpack .../30-libgudev-1.0-0_232-2+rpi1_armhf.deb ...
Unpacking libgudev-1.0-0:armhf (232-2+rpi1) ...
Selecting previously unselected package libwacom-common.
Preparing to unpack .../31-libwacom-common_0.32-1_all.deb ...
Unpacking libwacom-common (0.32-1) ...
Selecting previously unselected package libwacom2:armhf.
Preparing to unpack .../32-libwacom2_0.32-1_armhf.deb ...
Unpacking libwacom2:armhf (0.32-1) ...
Selecting previously unselected package libinput-bin.
Preparing to unpack .../33-libinput-bin_1.12.6-2+deb10u1_armhf.deb ...
Unpacking libinput-bin (1.12.6-2+deb10u1) ...
Selecting previously unselected package libmtdev1:armhf.
Preparing to unpack .../34-libmtdev1_1.1.5-1+b2_armhf.deb ...
Unpacking libmtdev1:armhf (1.1.5-1+b2) ...
Selecting previously unselected package libinput10:armhf.
Preparing to unpack .../35-libinput10_1.12.6-2+deb10u1_armhf.deb ...
Unpacking libinput10:armhf (1.12.6-2+deb10u1) ...
Selecting previously unselected package libpciaccess0:armhf.
Preparing to unpack .../36-libpciaccess0_0.14-1_armhf.deb ...
Unpacking libpciaccess0:armhf (0.14-1) ...
Selecting previously unselected package libunwind8:armhf.
Preparing to unpack .../37-libunwind8_1.2.1-10~deb10u1_armhf.deb ...
Unpacking libunwind8:armhf (1.2.1-10~deb10u1) ...
Selecting previously unselected package libutempter0:armhf.
Preparing to unpack .../38-libutempter0_1.1.6-3_armhf.deb ...
Unpacking libutempter0:armhf (1.1.6-3) ...
Selecting previously unselected package libwacom-bin.
Preparing to unpack .../39-libwacom-bin_0.32-1_armhf.deb ...
Unpacking libwacom-bin (0.32-1) ...
Selecting previously unselected package libxt6:armhf.
Preparing to unpack .../40-libxt6_1%3a1.1.5-1+b3_armhf.deb ...
Unpacking libxt6:armhf (1:1.1.5-1+b3) ...
Selecting previously unselected package libxmu6:armhf.
Preparing to unpack .../41-libxmu6_2%3a1.1.2-2+b3_armhf.deb ...
Unpacking libxmu6:armhf (2:1.1.2-2+b3) ...
Selecting previously unselected package libxpm4:armhf.
Preparing to unpack .../42-libxpm4_1%3a3.5.12-1+deb10u2_armhf.deb ...
Unpacking libxpm4:armhf (1:3.5.12-1+deb10u2) ...
Selecting previously unselected package libxaw7:armhf.
Preparing to unpack .../43-libxaw7_2%3a1.0.13-1+b2_armhf.deb ...
Unpacking libxaw7:armhf (2:1.0.13-1+b2) ...
Selecting previously unselected package libxcb-shape0:armhf.
Preparing to unpack .../44-libxcb-shape0_1.13.1-2_armhf.deb ...
Unpacking libxcb-shape0:armhf (1.13.1-2) ...
Selecting previously unselected package libxcomposite1:armhf.
Preparing to unpack .../45-libxcomposite1_1%3a0.4.4-2_armhf.deb ...
Unpacking libxcomposite1:armhf (1:0.4.4-2) ...
Selecting previously unselected package libxfont2:armhf.
Preparing to unpack .../46-libxfont2_1%3a2.0.3-1_armhf.deb ...
Unpacking libxfont2:armhf (1:2.0.3-1) ...
Selecting previously unselected package libxft2:armhf.
Preparing to unpack .../47-libxft2_2.3.2-2_armhf.deb ...
Unpacking libxft2:armhf (2.3.2-2) ...
Selecting previously unselected package libxkbfile1:armhf.
Preparing to unpack .../48-libxkbfile1_1%3a1.0.9-2_armhf.deb ...
Unpacking libxkbfile1:armhf (1:1.0.9-2) ...
Selecting previously unselected package libxv1:armhf.
Preparing to unpack .../49-libxv1_2%3a1.0.11-1_armhf.deb ...
Unpacking libxv1:armhf (2:1.0.11-1) ...
Selecting previously unselected package x11-utils.
Preparing to unpack .../50-x11-utils_7.7+4_armhf.deb ...
Unpacking x11-utils (7.7+4) ...
Selecting previously unselected package x11-xkb-utils.
Preparing to unpack .../51-x11-xkb-utils_7.7+4_armhf.deb ...
Unpacking x11-xkb-utils (7.7+4) ...
Selecting previously unselected package xbitmaps.
Preparing to unpack .../52-xbitmaps_1.1.1-2_all.deb ...
Unpacking xbitmaps (1.1.1-2) ...
Selecting previously unselected package xfonts-encodings.
Preparing to unpack .../53-xfonts-encodings_1%3a1.0.4-2_all.deb ...
Unpacking xfonts-encodings (1:1.0.4-2) ...
Selecting previously unselected package xfonts-utils.
Preparing to unpack .../54-xfonts-utils_1%3a7.7+6_armhf.deb ...
Unpacking xfonts-utils (1:7.7+6) ...
Selecting previously unselected package xfonts-base.
Preparing to unpack .../55-xfonts-base_1%3a1.0.5_all.deb ...
Unpacking xfonts-base (1:1.0.5) ...
Selecting previously unselected package xinit.
Preparing to unpack .../56-xinit_1.4.0-1_armhf.deb ...
Unpacking xinit (1.4.0-1) ...
Selecting previously unselected package xserver-common.
Preparing to unpack .../57-xserver-common_2%3a1.20.4-1+rpt4+deb10u9_all.deb ...
Unpacking xserver-common (2:1.20.4-1+rpt4+deb10u9) ...
Selecting previously unselected package xserver-xorg-core.
Preparing to unpack .../58-xserver-xorg-core_2%3a1.20.4-1+rpt4+deb10u9_armhf.deb ...
Unpacking xserver-xorg-core (2:1.20.4-1+rpt4+deb10u9) ...
Selecting previously unselected package xserver-xorg-video-amdgpu.
Preparing to unpack .../59-xserver-xorg-video-amdgpu_18.1.99+git20190207-1_armhf.deb ...
Unpacking xserver-xorg-video-amdgpu (18.1.99+git20190207-1) ...
Selecting previously unselected package xserver-xorg-video-radeon.
Preparing to unpack .../60-xserver-xorg-video-radeon_1%3a19.0.1-1_armhf.deb ...
Unpacking xserver-xorg-video-radeon (1:19.0.1-1) ...
Selecting previously unselected package xserver-xorg-video-ati.
Preparing to unpack .../61-xserver-xorg-video-ati_1%3a19.0.1-1_armhf.deb ...
Unpacking xserver-xorg-video-ati (1:19.0.1-1) ...
Selecting previously unselected package xserver-xorg-video-fbdev.
Preparing to unpack .../62-xserver-xorg-video-fbdev_1%3a0.5.0-1+b2_armhf.deb ...
Unpacking xserver-xorg-video-fbdev (1:0.5.0-1+b2) ...
Selecting previously unselected package xserver-xorg-video-nouveau.
Preparing to unpack .../63-xserver-xorg-video-nouveau_1%3a1.0.16-1_armhf.deb ...
Unpacking xserver-xorg-video-nouveau (1:1.0.16-1) ...
Selecting previously unselected package xserver-xorg-video-vesa.
Preparing to unpack .../64-xserver-xorg-video-vesa_1%3a2.4.0-1+b1_armhf.deb ...
Unpacking xserver-xorg-video-vesa (1:2.4.0-1+b1) ...
Selecting previously unselected package xserver-xorg-video-all.
Preparing to unpack .../65-xserver-xorg-video-all_1%3a7.7+19+b8_armhf.deb ...
Unpacking xserver-xorg-video-all (1:7.7+19+b8) ...
Selecting previously unselected package xserver-xorg-input-libinput.
Preparing to unpack .../66-xserver-xorg-input-libinput_0.28.2-2_armhf.deb ...
Unpacking xserver-xorg-input-libinput (0.28.2-2) ...
Selecting previously unselected package xserver-xorg-input-all.
Preparing to unpack .../67-xserver-xorg-input-all_1%3a7.7+19+b8_armhf.deb ...
Unpacking xserver-xorg-input-all (1:7.7+19+b8) ...
Selecting previously unselected package xserver-xorg-input-wacom.
Preparing to unpack .../68-xserver-xorg-input-wacom_0.34.99.1-1+b6_armhf.deb ...
Unpacking xserver-xorg-input-wacom (0.34.99.1-1+b6) ...
Selecting previously unselected package xserver-xorg.
Preparing to unpack .../69-xserver-xorg_1%3a7.7+19+b8_armhf.deb ...
Unpacking xserver-xorg (1:7.7+19+b8) ...
Selecting previously unselected package xserver-xorg-legacy.
Preparing to unpack .../70-xserver-xorg-legacy_2%3a1.20.4-1+rpt4+deb10u9_armhf.deb ...
Unpacking xserver-xorg-legacy (2:1.20.4-1+rpt4+deb10u9) ...
Selecting previously unselected package xterm.
Preparing to unpack .../71-xterm_344-1+deb10u2_armhf.deb ...
Unpacking xterm (344-1+deb10u2) ...
Setting up libxcb-dri3-0:armhf (1.13.1-2) ...
Setting up xinit (1.4.0-1) ...
Setting up libwayland-server0:armhf (1.16.0-1) ...
Setting up libpciaccess0:armhf (0.14-1) ...
Setting up libxft2:armhf (2.3.2-2) ...
Setting up libdrm-nouveau2:armhf (2.4.100-4+rpi1~bpo10+1) ...
Setting up libxdamage1:armhf (1:1.1.4-3+b3) ...
Setting up libxcb-xfixes0:armhf (1.13.1-2) ...
Setting up libxpm4:armhf (1:3.5.12-1+deb10u2) ...
Setting up libgbm1:armhf (19.3.2-1~bpo10+1~rpt4) ...
Setting up libdrm-radeon1:armhf (2.4.100-4+rpi1~bpo10+1) ...
Setting up libglvnd0:armhf (1.3.0-7~bpo10+1) ...
Setting up libxcb-glx0:armhf (1.13.1-2) ...
Setting up libxcb-shape0:armhf (1.13.1-2) ...
Setting up libsensors-config (1:3.5.0-3) ...
Setting up libxxf86dga1:armhf (2:1.1.4-1) ...
Setting up libunwind8:armhf (1.2.1-10~deb10u1) ...
Setting up libxcb-present0:armhf (1.13.1-2) ...
Setting up libfontenc1:armhf (1:1.1.3-1) ...
Setting up libepoxy0:armhf (1.5.3-0.1) ...
Setting up libxcb-sync1:armhf (1.13.1-2) ...
Setting up xfonts-encodings (1:1.0.4-2) ...
Setting up libxv1:armhf (2:1.0.11-1) ...
Setting up libsensors5:armhf (1:3.5.0-3) ...
Setting up libxt6:armhf (1:1.1.5-1+b3) ...
Setting up libglapi-mesa:armhf (19.3.2-1~bpo10+1~rpt4) ...
Setting up libmtdev1:armhf (1.1.5-1+b2) ...
Setting up libutempter0:armhf (1.1.6-3) ...
Setting up libxcb-dri2-0:armhf (1.13.1-2) ...
Setting up libxshmfence1:armhf (1.3-1) ...
Setting up libxkbfile1:armhf (1:1.0.9-2) ...
Setting up keyboard-configuration (1.193~deb10u1) ...
Setting up libxcomposite1:armhf (1:0.4.4-2) ...
Setting up libxfont2:armhf (1:2.0.3-1) ...
Setting up libevdev2:armhf (1.6.0+dfsg-1) ...
Setting up libllvm9:armhf (1:9.0.1-6+rpi1~bpo10+1) ...
Setting up libgudev-1.0-0:armhf (232-2+rpi1) ...
Setting up xbitmaps (1.1.1-2) ...
Setting up libdrm-amdgpu1:armhf (2.4.100-4+rpi1~bpo10+1) ...
Setting up libwacom-common (0.32-1) ...
Setting up libxmu6:armhf (2:1.1.2-2+b3) ...
Setting up libgl1-mesa-dri:armhf (19.3.2-1~bpo10+1~rpt4) ...
Setting up libxaw7:armhf (2:1.0.13-1+b2) ...
Setting up xfonts-utils (1:7.7+6) ...
Setting up xfonts-base (1:1.0.5) ...
Setting up libegl-mesa0:armhf (19.3.2-1~bpo10+1~rpt4) ...
Setting up libegl1:armhf (1.3.0-7~bpo10+1) ...
Setting up xterm (344-1+deb10u2) ...
update-alternatives: using /usr/bin/xterm to provide /usr/bin/x-terminal-emulator (x-terminal-emulator) in auto mode
update-alternatives: using /usr/bin/lxterm to provide /usr/bin/x-terminal-emulator (x-terminal-emulator) in auto mode
Setting up libwacom2:armhf (0.32-1) ...
Setting up libglx-mesa0:armhf (19.3.2-1~bpo10+1~rpt4) ...
Setting up libglx0:armhf (1.3.0-7~bpo10+1) ...
Setting up x11-xkb-utils (7.7+4) ...
Setting up libinput-bin (1.12.6-2+deb10u1) ...
Setting up libegl1-mesa:armhf (19.3.2-1~bpo10+1~rpt4) ...
Setting up libgl1:armhf (1.3.0-7~bpo10+1) ...
Setting up libwacom-bin (0.32-1) ...
Setting up x11-utils (7.7+4) ...
Setting up xserver-common (2:1.20.4-1+rpt4+deb10u9) ...
Setting up xserver-xorg-legacy (2:1.20.4-1+rpt4+deb10u9) ...
Setting up libinput10:armhf (1.12.6-2+deb10u1) ...
Setting up xserver-xorg-core (2:1.20.4-1+rpt4+deb10u9) ...
Setting up xserver-xorg-video-radeon (1:19.0.1-1) ...
Setting up xserver-xorg-input-wacom (0.34.99.1-1+b6) ...
Setting up xserver-xorg-video-fbdev (1:0.5.0-1+b2) ...
Setting up xserver-xorg-video-vesa (1:2.4.0-1+b1) ...
Setting up xserver-xorg-video-amdgpu (18.1.99+git20190207-1) ...
Setting up xserver-xorg (1:7.7+19+b8) ...
Setting up xserver-xorg-video-nouveau (1:1.0.16-1) ...
Setting up xserver-xorg-input-libinput (0.28.2-2) ...
Setting up xserver-xorg-video-ati (1:19.0.1-1) ...
Setting up xserver-xorg-video-all (1:7.7+19+b8) ...
Setting up xserver-xorg-input-all (1:7.7+19+b8) ...
Processing triggers for man-db (2.8.5-2) ...
Processing triggers for fontconfig (2.13.1-2) ...
Processing triggers for mime-support (3.62) ...
Processing triggers for libc-bin (2.28-10+rpt2+rpi1) ...
Reading package lists...
Building dependency tree...
Reading state information...
The following additional packages will be installed:
libglu1-mesa x11-apps x11-session-utils x11-xserver-utils xfonts-100dpi
xfonts-75dpi xfonts-scalable xorg-docs-core
Suggested packages:
mesa-utils nickle cairo-5c xorg-docs x11-xfs-utils
The following NEW packages will be installed:
libglu1-mesa x11-apps x11-session-utils x11-xserver-utils xfonts-100dpi
xfonts-75dpi xfonts-scalable xorg xorg-docs-core
0 upgraded, 9 newly installed, 0 to remove and 207 not upgraded.
Need to get 0 B/8497 kB of archives.
After this operation, 11.5 MB of additional disk space will be used.
Selecting previously unselected package libglu1-mesa:armhf.
(Reading database ... (Reading database ... 5% (Reading database ... 10% dpkg: warning: files list file for package 'plymouth-themes' missing; assuming package has no files currently installed
(Reading database ... 15% dpkg: warning: files list file for package 'libxslt1.1:armhf' missing; assuming package has no files currently installed
(Reading database ... 20% (Reading database ... 25% (Reading database ... 30% (Reading database ... 35% (Reading database ... 40% (Reading database ... 45% (Reading database ... 50% (Reading database ... 55% (Reading database ... 60% (Reading database ... 65% (Reading database ... 70% (Reading database ... 75% (Reading database ... 80% (Reading database ... 85% (Reading database ... 90% (Reading database ... 95% (Reading database ... 100% (Reading database ... 37957 files and directories currently installed.)
Preparing to unpack .../0-libglu1-mesa_9.0.0-2.1_armhf.deb ...
Unpacking libglu1-mesa:armhf (9.0.0-2.1) ...
Selecting previously unselected package x11-apps.
Preparing to unpack .../1-x11-apps_7.7+7_armhf.deb ...
Unpacking x11-apps (7.7+7) ...
Selecting previously unselected package x11-session-utils.
Preparing to unpack .../2-x11-session-utils_7.7+3_armhf.deb ...
Unpacking x11-session-utils (7.7+3) ...
Selecting previously unselected package x11-xserver-utils.
Preparing to unpack .../3-x11-xserver-utils_7.7+8+rpt1_armhf.deb ...
Unpacking x11-xserver-utils (7.7+8+rpt1) ...
Selecting previously unselected package xfonts-100dpi.
Preparing to unpack .../4-xfonts-100dpi_1%3a1.0.4+nmu1_all.deb ...
Unpacking xfonts-100dpi (1:1.0.4+nmu1) ...
Selecting previously unselected package xfonts-75dpi.
Preparing to unpack .../5-xfonts-75dpi_1%3a1.0.4+nmu1_all.deb ...
Unpacking xfonts-75dpi (1:1.0.4+nmu1) ...
Selecting previously unselected package xfonts-scalable.
Preparing to unpack .../6-xfonts-scalable_1%3a1.0.3-1.1_all.deb ...
Unpacking xfonts-scalable (1:1.0.3-1.1) ...
Selecting previously unselected package xorg-docs-core.
Preparing to unpack .../7-xorg-docs-core_1%3a1.7.1-1.1_all.deb ...
Unpacking xorg-docs-core (1:1.7.1-1.1) ...
Selecting previously unselected package xorg.
Preparing to unpack .../8-xorg_1%3a7.7+19+b8_armhf.deb ...
Unpacking xorg (1:7.7+19+b8) ...
Setting up xfonts-100dpi (1:1.0.4+nmu1) ...
Setting up x11-apps (7.7+7) ...
Setting up x11-xserver-utils (7.7+8+rpt1) ...
Setting up xorg-docs-core (1:1.7.1-1.1) ...
Setting up x11-session-utils (7.7+3) ...
Setting up libglu1-mesa:armhf (9.0.0-2.1) ...
Setting up xfonts-75dpi (1:1.0.4+nmu1) ...
Setting up xfonts-scalable (1:1.0.3-1.1) ...
Setting up xorg (1:7.7+19+b8) ...
Processing triggers for man-db (2.8.5-2) ...
Processing triggers for fontconfig (2.13.1-2) ...
Reading package lists...
Building dependency tree...
Reading state information...
The following additional packages will be installed:
adwaita-icon-theme at-spi2-core dconf-gsettings-backend dconf-service
giblib1 glib-networking glib-networking-common glib-networking-services
gnome-icon-theme gsettings-desktop-schemas gtk-update-icon-cache
hicolor-icon-theme libatk-bridge2.0-0 libatk1.0-0 libatk1.0-data
libatspi2.0-0 libcairo-gobject2 libcolord2 libdconf1 libgail-common
libgail18 libgif7 libgtk-3-0 libgtk-3-bin libgtk-3-common libgtk2.0-0
libgtk2.0-bin libgtk2.0-common libimlib2 libjson-glib-1.0-0
libjson-glib-1.0-common liblcms2-2 libobrender32v5 libobt2v5
libpangoxft-1.0-0 libproxy1v5 librest-0.7-0 libsoup-gnome2.4-1 libsoup2.4-1
libstartup-notification0 libxcb-util0 obconf obsession scrot
Suggested packages:
colord gvfs liblcms2-utils fonts-dejavu libxml2-dev tint2
openbox-gnome-session openbox-kde-session
The following NEW packages will be installed:
adwaita-icon-theme at-spi2-core dconf-gsettings-backend dconf-service
giblib1 glib-networking glib-networking-common glib-networking-services
gnome-icon-theme gsettings-desktop-schemas gtk-update-icon-cache
hicolor-icon-theme libatk-bridge2.0-0 libatk1.0-0 libatk1.0-data
libatspi2.0-0 libcairo-gobject2 libcolord2 libdconf1 libgail-common
libgail18 libgif7 libgtk-3-0 libgtk-3-bin libgtk-3-common libgtk2.0-0
libgtk2.0-bin libgtk2.0-common libimlib2 libjson-glib-1.0-0
libjson-glib-1.0-common liblcms2-2 libobrender32v5 libobt2v5
libpangoxft-1.0-0 libproxy1v5 librest-0.7-0 libsoup-gnome2.4-1 libsoup2.4-1
libstartup-notification0 libxcb-util0 obconf obsession openbox scrot
0 upgraded, 45 newly installed, 0 to remove and 207 not upgraded.
Need to get 0 B/34.9 MB of archives.
After this operation, 116 MB of additional disk space will be used.
Selecting previously unselected package hicolor-icon-theme.
(Reading database ... (Reading database ... 5% (Reading database ... 10% dpkg: warning: files list file for package 'plymouth-themes' missing; assuming package has no files currently installed
(Reading database ... 15% dpkg: warning: files list file for package 'libxslt1.1:armhf' missing; assuming package has no files currently installed
(Reading database ... 20% (Reading database ... 25% (Reading database ... 30% (Reading database ... 35% (Reading database ... 40% (Reading database ... 45% (Reading database ... 50% (Reading database ... 55% (Reading database ... 60% (Reading database ... 65% (Reading database ... 70% (Reading database ... 75% (Reading database ... 80% (Reading database ... 85% (Reading database ... 90% (Reading database ... 95% (Reading database ... 100% (Reading database ... 38941 files and directories currently installed.)
Preparing to unpack .../00-hicolor-icon-theme_0.17-2_all.deb ...
Unpacking hicolor-icon-theme (0.17-2) ...
Selecting previously unselected package gtk-update-icon-cache.
Preparing to unpack .../01-gtk-update-icon-cache_3.24.5-1+rpt2_armhf.deb ...
No diversion 'diversion of /usr/sbin/update-icon-caches to /usr/sbin/update-icon-caches.gtk2 by libgtk-3-bin', none removed.
No diversion 'diversion of /usr/share/man/man8/update-icon-caches.8.gz to /usr/share/man/man8/update-icon-caches.gtk2.8.gz by libgtk-3-bin', none removed.
Unpacking gtk-update-icon-cache (3.24.5-1+rpt2) ...
Selecting previously unselected package adwaita-icon-theme.
Preparing to unpack .../02-adwaita-icon-theme_3.30.1-1_all.deb ...
Unpacking adwaita-icon-theme (3.30.1-1) ...
Selecting previously unselected package libatspi2.0-0:armhf.
Preparing to unpack .../03-libatspi2.0-0_2.30.0-7_armhf.deb ...
Unpacking libatspi2.0-0:armhf (2.30.0-7) ...
Selecting previously unselected package at-spi2-core.
Preparing to unpack .../04-at-spi2-core_2.30.0-7_armhf.deb ...
Unpacking at-spi2-core (2.30.0-7) ...
Selecting previously unselected package libdconf1:armhf.
Preparing to unpack .../05-libdconf1_0.30.1-2_armhf.deb ...
Unpacking libdconf1:armhf (0.30.1-2) ...
Selecting previously unselected package dconf-service.
Preparing to unpack .../06-dconf-service_0.30.1-2_armhf.deb ...
Unpacking dconf-service (0.30.1-2) ...
Selecting previously unselected package dconf-gsettings-backend:armhf.
Preparing to unpack .../07-dconf-gsettings-backend_0.30.1-2_armhf.deb ...
Unpacking dconf-gsettings-backend:armhf (0.30.1-2) ...
Selecting previously unselected package libgif7:armhf.
Preparing to unpack .../08-libgif7_5.1.4-3+deb10u1_armhf.deb ...
Unpacking libgif7:armhf (5.1.4-3+deb10u1) ...
Selecting previously unselected package libimlib2:armhf.
Preparing to unpack .../09-libimlib2_1.5.1-1_armhf.deb ...
Unpacking libimlib2:armhf (1.5.1-1) ...
Selecting previously unselected package giblib1:armhf.
Preparing to unpack .../10-giblib1_1.2.4-12_armhf.deb ...
Unpacking giblib1:armhf (1.2.4-12) ...
Selecting previously unselected package libproxy1v5:armhf.
Preparing to unpack .../11-libproxy1v5_0.4.15-5+deb10u1_armhf.deb ...
Unpacking libproxy1v5:armhf (0.4.15-5+deb10u1) ...
Selecting previously unselected package glib-networking-common.
Preparing to unpack .../12-glib-networking-common_2.58.0-2+deb10u2_all.deb ...
Unpacking glib-networking-common (2.58.0-2+deb10u2) ...
Selecting previously unselected package glib-networking-services.
Preparing to unpack .../13-glib-networking-services_2.58.0-2+deb10u2_armhf.deb ...
Unpacking glib-networking-services (2.58.0-2+deb10u2) ...
Selecting previously unselected package gsettings-desktop-schemas.
Preparing to unpack .../14-gsettings-desktop-schemas_3.28.1-1_all.deb ...
Unpacking gsettings-desktop-schemas (3.28.1-1) ...
Selecting previously unselected package glib-networking:armhf.
Preparing to unpack .../15-glib-networking_2.58.0-2+deb10u2_armhf.deb ...
Unpacking glib-networking:armhf (2.58.0-2+deb10u2) ...
Selecting previously unselected package gnome-icon-theme.
Preparing to unpack .../16-gnome-icon-theme_3.12.0-3_all.deb ...
Unpacking gnome-icon-theme (3.12.0-3) ...
Selecting previously unselected package libatk1.0-data.
Preparing to unpack .../17-libatk1.0-data_2.30.0-2_all.deb ...
Unpacking libatk1.0-data (2.30.0-2) ...
Selecting previously unselected package libatk1.0-0:armhf.
Preparing to unpack .../18-libatk1.0-0_2.30.0-2_armhf.deb ...
Unpacking libatk1.0-0:armhf (2.30.0-2) ...
Selecting previously unselected package libatk-bridge2.0-0:armhf.
Preparing to unpack .../19-libatk-bridge2.0-0_2.30.0-5_armhf.deb ...
Unpacking libatk-bridge2.0-0:armhf (2.30.0-5) ...
Selecting previously unselected package libcairo-gobject2:armhf.
Preparing to unpack .../20-libcairo-gobject2_1.16.0-4+rpt1+deb10u1_armhf.deb ...
Unpacking libcairo-gobject2:armhf (1.16.0-4+rpt1+deb10u1) ...
Selecting previously unselected package liblcms2-2:armhf.
Preparing to unpack .../21-liblcms2-2_2.9-3_armhf.deb ...
Unpacking liblcms2-2:armhf (2.9-3) ...
Selecting previously unselected package libcolord2:armhf.
Preparing to unpack .../22-libcolord2_1.4.3-4_armhf.deb ...
Unpacking libcolord2:armhf (1.4.3-4) ...
Selecting previously unselected package libgtk2.0-common.
Preparing to unpack .../23-libgtk2.0-common_2.24.32-3+rpt1_all.deb ...
Unpacking libgtk2.0-common (2.24.32-3+rpt1) ...
Selecting previously unselected package libgtk2.0-0:armhf.
Preparing to unpack .../24-libgtk2.0-0_2.24.32-3+rpt1_armhf.deb ...
Unpacking libgtk2.0-0:armhf (2.24.32-3+rpt1) ...
Selecting previously unselected package libgail18:armhf.
Preparing to unpack .../25-libgail18_2.24.32-3+rpt1_armhf.deb ...
Unpacking libgail18:armhf (2.24.32-3+rpt1) ...
Selecting previously unselected package libgail-common:armhf.
Preparing to unpack .../26-libgail-common_2.24.32-3+rpt1_armhf.deb ...
Unpacking libgail-common:armhf (2.24.32-3+rpt1) ...
Selecting previously unselected package libjson-glib-1.0-common.
Preparing to unpack .../27-libjson-glib-1.0-common_1.4.4-2_all.deb ...
Unpacking libjson-glib-1.0-common (1.4.4-2) ...
Selecting previously unselected package libjson-glib-1.0-0:armhf.
Preparing to unpack .../28-libjson-glib-1.0-0_1.4.4-2_armhf.deb ...
Unpacking libjson-glib-1.0-0:armhf (1.4.4-2) ...
Selecting previously unselected package libsoup2.4-1:armhf.
Preparing to unpack .../29-libsoup2.4-1_2.64.2-2_armhf.deb ...
Unpacking libsoup2.4-1:armhf (2.64.2-2) ...
Selecting previously unselected package libsoup-gnome2.4-1:armhf.
Preparing to unpack .../30-libsoup-gnome2.4-1_2.64.2-2_armhf.deb ...
Unpacking libsoup-gnome2.4-1:armhf (2.64.2-2) ...
Selecting previously unselected package librest-0.7-0:armhf.
Preparing to unpack .../31-librest-0.7-0_0.8.1-1_armhf.deb ...
Unpacking librest-0.7-0:armhf (0.8.1-1) ...
Selecting previously unselected package libgtk-3-common.
Preparing to unpack .../32-libgtk-3-common_3.24.5-1+rpt2_all.deb ...
Unpacking libgtk-3-common (3.24.5-1+rpt2) ...
Selecting previously unselected package libgtk-3-0:armhf.
Preparing to unpack .../33-libgtk-3-0_3.24.5-1+rpt2_armhf.deb ...
Unpacking libgtk-3-0:armhf (3.24.5-1+rpt2) ...
Selecting previously unselected package libgtk-3-bin.
Preparing to unpack .../34-libgtk-3-bin_3.24.5-1+rpt2_armhf.deb ...
Unpacking libgtk-3-bin (3.24.5-1+rpt2) ...
Selecting previously unselected package libgtk2.0-bin.
Preparing to unpack .../35-libgtk2.0-bin_2.24.32-3+rpt1_armhf.deb ...
Unpacking libgtk2.0-bin (2.24.32-3+rpt1) ...
Selecting previously unselected package libobt2v5.
Preparing to unpack .../36-libobt2v5_3.6.1-8+rpt5_armhf.deb ...
Unpacking libobt2v5 (3.6.1-8+rpt5) ...
Selecting previously unselected package libpangoxft-1.0-0:armhf.
Preparing to unpack .../37-libpangoxft-1.0-0_1.42.4-8~deb10u1_armhf.deb ...
Unpacking libpangoxft-1.0-0:armhf (1.42.4-8~deb10u1) ...
Selecting previously unselected package libobrender32v5.
Preparing to unpack .../38-libobrender32v5_3.6.1-8+rpt5_armhf.deb ...
Unpacking libobrender32v5 (3.6.1-8+rpt5) ...
Selecting previously unselected package libxcb-util0:armhf.
Preparing to unpack .../39-libxcb-util0_0.3.8-3+b2_armhf.deb ...
Unpacking libxcb-util0:armhf (0.3.8-3+b2) ...
Selecting previously unselected package libstartup-notification0:armhf.
Preparing to unpack .../40-libstartup-notification0_0.12-6_armhf.deb ...
Unpacking libstartup-notification0:armhf (0.12-6) ...
Selecting previously unselected package obconf.
Preparing to unpack .../41-obconf_1%3a2.0.4+git20150213-2+rpt4_armhf.deb ...
Unpacking obconf (1:2.0.4+git20150213-2+rpt4) ...
Selecting previously unselected package openbox.
Preparing to unpack .../42-openbox_3.6.1-8+rpt5_armhf.deb ...
Unpacking openbox (3.6.1-8+rpt5) ...
Selecting previously unselected package scrot.
Preparing to unpack .../43-scrot_0.9-1_armhf.deb ...
Unpacking scrot (0.9-1) ...
Selecting previously unselected package obsession.
Preparing to unpack .../44-obsession_20140608-2_armhf.deb ...
Unpacking obsession (20140608-2) ...
Setting up liblcms2-2:armhf (2.9-3) ...
Setting up gtk-update-icon-cache (3.24.5-1+rpt2) ...
Setting up libproxy1v5:armhf (0.4.15-5+deb10u1) ...
Setting up libpangoxft-1.0-0:armhf (1.42.4-8~deb10u1) ...
Setting up hicolor-icon-theme (0.17-2) ...
Setting up libatspi2.0-0:armhf (2.30.0-7) ...
Setting up libxcb-util0:armhf (0.3.8-3+b2) ...
Setting up gnome-icon-theme (3.12.0-3) ...
update-alternatives: using /usr/share/icons/gnome/scalable/places/debian-swirl.svg to provide /usr/share/icons/gnome/scalable/places/start-here.svg (start-here.svg) in auto mode
Setting up libcolord2:armhf (1.4.3-4) ...
Setting up libdconf1:armhf (0.30.1-2) ...
Setting up adwaita-icon-theme (3.30.1-1) ...
update-alternatives: using /usr/share/icons/Adwaita/cursor.theme to provide /usr/share/icons/default/index.theme (x-cursor-theme) in auto mode
Setting up libobt2v5 (3.6.1-8+rpt5) ...
Setting up libgif7:armhf (5.1.4-3+deb10u1) ...
Setting up libatk1.0-data (2.30.0-2) ...
Setting up at-spi2-core (2.30.0-7) ...
Setting up libjson-glib-1.0-common (1.4.4-2) ...
Setting up libcairo-gobject2:armhf (1.16.0-4+rpt1+deb10u1) ...
Setting up libgtk2.0-common (2.24.32-3+rpt1) ...
Setting up libatk1.0-0:armhf (2.30.0-2) ...
Setting up glib-networking-common (2.58.0-2+deb10u2) ...
Setting up libstartup-notification0:armhf (0.12-6) ...
Setting up glib-networking-services (2.58.0-2+deb10u2) ...
Setting up libgtk2.0-0:armhf (2.24.32-3+rpt1) ...
Setting up dconf-service (0.30.1-2) ...
Setting up obsession (20140608-2) ...
Setting up libjson-glib-1.0-0:armhf (1.4.4-2) ...
Setting up libatk-bridge2.0-0:armhf (2.30.0-5) ...
Setting up libimlib2:armhf (1.5.1-1) ...
Setting up libgail18:armhf (2.24.32-3+rpt1) ...
Setting up libgtk2.0-bin (2.24.32-3+rpt1) ...
Setting up libobrender32v5 (3.6.1-8+rpt5) ...
Setting up dconf-gsettings-backend:armhf (0.30.1-2) ...
Setting up libgail-common:armhf (2.24.32-3+rpt1) ...
Setting up giblib1:armhf (1.2.4-12) ...
Setting up openbox (3.6.1-8+rpt5) ...
update-alternatives: using /usr/bin/openbox to provide /usr/bin/x-window-manager (x-window-manager) in auto mode
update-alternatives: using /usr/bin/openbox-session to provide /usr/bin/x-session-manager (x-session-manager) in auto mode
Setting up scrot (0.9-1) ...
Setting up libgtk-3-common (3.24.5-1+rpt2) ...
Setting up gsettings-desktop-schemas (3.28.1-1) ...
Processing triggers for mime-support (3.62) ...
Processing triggers for libglib2.0-0:armhf (2.58.3-2+deb10u2) ...
Processing triggers for libc-bin (2.28-10+rpt2+rpi1) ...
Processing triggers for man-db (2.8.5-2) ...
Processing triggers for shared-mime-info (1.10-1) ...
Setting up glib-networking:armhf (2.58.0-2+deb10u2) ...
Setting up libsoup2.4-1:armhf (2.64.2-2) ...
Setting up libsoup-gnome2.4-1:armhf (2.64.2-2) ...
Setting up librest-0.7-0:armhf (0.8.1-1) ...
Setting up libgtk-3-0:armhf (3.24.5-1+rpt2) ...
Setting up libgtk-3-bin (3.24.5-1+rpt2) ...
Setting up obconf (1:2.0.4+git20150213-2+rpt4) ...
Processing triggers for libc-bin (2.28-10+rpt2+rpi1) ...
Creating /etc/X11/xorg.conf.d dir
Creating Xorg configuration
Installing Chromium
Reading package lists...
Building dependency tree...
Reading state information...
Some packages could not be installed. This may mean that you have
requested an impossible situation or if you are using the unstable
distribution that some required packages have not yet been created
or been moved out of Incoming.
The following information may help to resolve the situation:
The following packages have unmet dependencies:
chromium-browser : Depends: chromium-codecs-ffmpeg-extra (= 92.0.4515.98~buster-rpt2) but it is not going to be installed or
chromium-codecs-ffmpeg (= 92.0.4515.98~buster-rpt2) but it is not going to be installed
Depends: libraspberrypi0 but it is not installable
Recommends: chromium-browser-l10n but it is not going to be installed
Installation of Chromium failed
Plugin failed to install!
Cleaning up...
Removing dependencies
Reading package lists...
Building dependency tree...
Reading state information...
Package 'fonts-arphic-ukai' is not installed, so not removed
0 upgraded, 0 newly installed, 0 to remove and 207 not upgraded.
Reading package lists...
Building dependency tree...
Reading state information...
Package 'fonts-arphic-gbsn00lp' is not installed, so not removed
0 upgraded, 0 newly installed, 0 to remove and 207 not upgraded.
Reading package lists...
Building dependency tree...
Reading state information...
Package 'fonts-unfonts-core' is not installed, so not removed
0 upgraded, 0 newly installed, 0 to remove and 207 not upgraded.
Reading package lists...
Building dependency tree...
Reading state information...
Package 'fonts-ipafont' is not installed, so not removed
0 upgraded, 0 newly installed, 0 to remove and 207 not upgraded.
Reading package lists...
Building dependency tree...
Reading state information...
Package 'fonts-vlgothic' is not installed, so not removed
0 upgraded, 0 newly installed, 0 to remove and 207 not upgraded.
Reading package lists...
Building dependency tree...
Reading state information...
Package 'fonts-thai-tlwg-ttf' is not installed, so not removed
0 upgraded, 0 newly installed, 0 to remove and 207 not upgraded.
Reading package lists...
Building dependency tree...
Reading state information...
Package 'chromium-browser' is not installed, so not removed
0 upgraded, 0 newly installed, 0 to remove and 207 not upgraded.
Reading package lists...
Building dependency tree...
Reading state information...
The following packages will be REMOVED:
adwaita-icon-theme* at-spi2-core* dconf-gsettings-backend* dconf-service*
giblib1* glib-networking* glib-networking-common* glib-networking-services*
gnome-icon-theme* gsettings-desktop-schemas* gtk-update-icon-cache*
hicolor-icon-theme* libatk-bridge2.0-0* libatk1.0-0* libatk1.0-data*
libatspi2.0-0* libcairo-gobject2* libcolord2* libdconf1* libgail-common*
libgail18* libgif7* libgtk-3-0* libgtk-3-bin* libgtk-3-common* libgtk2.0-0*
libgtk2.0-bin* libgtk2.0-common* libimlib2* libjson-glib-1.0-0*
libjson-glib-1.0-common* liblcms2-2* libobrender32v5* libobt2v5*
libpangoxft-1.0-0* libproxy1v5* librest-0.7-0* libsoup-gnome2.4-1*
libsoup2.4-1* libstartup-notification0* libxcb-util0* obconf* obsession*
openbox* scrot*
0 upgraded, 0 newly installed, 45 to remove and 207 not upgraded.
After this operation, 116 MB disk space will be freed.
(Reading database ... (Reading database ... 5% (Reading database ... 10% dpkg: warning: files list file for package 'plymouth-themes' missing; assuming package has no files currently installed
(Reading database ... 15% dpkg: warning: files list file for package 'libxslt1.1:armhf' missing; assuming package has no files currently installed
(Reading database ... 20% (Reading database ... 25% (Reading database ... 30% (Reading database ... 35% (Reading database ... 40% (Reading database ... 45% (Reading database ... 50% (Reading database ... 55% (Reading database ... 60% (Reading database ... 65% (Reading database ... 70% (Reading database ... 75% (Reading database ... 80% (Reading database ... 85% (Reading database ... 90% (Reading database ... 95% (Reading database ... 100% (Reading database ... 52732 files and directories currently installed.)
Removing libgtk2.0-bin (2.24.32-3+rpt1) ...
Removing libgail-common:armhf (2.24.32-3+rpt1) ...
Removing libgail18:armhf (2.24.32-3+rpt1) ...
Removing obconf (1:2.0.4+git20150213-2+rpt4) ...
Removing at-spi2-core (2.30.0-7) ...
Removing libgtk-3-bin (3.24.5-1+rpt2) ...
Removing scrot (0.9-1) ...
Removing giblib1:armhf (1.2.4-12) ...
Removing gnome-icon-theme (3.12.0-3) ...
update-alternatives: using /usr/share/icons/gnome/scalable/places/gnome-foot.svg to provide /usr/share/icons/gnome/scalable/places/start-here.svg (start-here.svg) in auto mode
update-alternatives: warning: skip creation of /usr/share/icons/gnome/256x256/places/start-here.png because associated file /usr/share/icons/gnome/256x256/places/gnome-foot.png (of link group start-here.svg) doesn't exist
Removing openbox (3.6.1-8+rpt5) ...
Removing libobrender32v5 (3.6.1-8+rpt5) ...
Removing libimlib2:armhf (1.5.1-1) ...
Removing libgif7:armhf (5.1.4-3+deb10u1) ...
Removing libobt2v5 (3.6.1-8+rpt5) ...
Removing libpangoxft-1.0-0:armhf (1.42.4-8~deb10u1) ...
Removing libstartup-notification0:armhf (0.12-6) ...
Removing libxcb-util0:armhf (0.3.8-3+b2) ...
Removing obsession (20140608-2) ...
Removing libgtk2.0-0:armhf (2.24.32-3+rpt1) ...
Removing libgtk-3-0:armhf (3.24.5-1+rpt2) ...
Removing adwaita-icon-theme (3.30.1-1) ...
Removing libgtk-3-common (3.24.5-1+rpt2) ...
Removing librest-0.7-0:armhf (0.8.1-1) ...
Removing libsoup-gnome2.4-1:armhf (2.64.2-2) ...
Removing libsoup2.4-1:armhf (2.64.2-2) ...
Removing glib-networking:armhf (2.58.0-2+deb10u2) ...
Removing gsettings-desktop-schemas (3.28.1-1) ...
Removing dconf-gsettings-backend:armhf (0.30.1-2) ...
Removing dconf-service (0.30.1-2) ...
Removing glib-networking-services (2.58.0-2+deb10u2) ...
Removing glib-networking-common (2.58.0-2+deb10u2) ...
Removing gtk-update-icon-cache (3.24.5-1+rpt2) ...
Removing hicolor-icon-theme (0.17-2) ...
Removing libatk-bridge2.0-0:armhf (2.30.0-5) ...
Removing libatk1.0-0:armhf (2.30.0-2) ...
Removing libatk1.0-data (2.30.0-2) ...
Removing libatspi2.0-0:armhf (2.30.0-7) ...
Removing libcairo-gobject2:armhf (1.16.0-4+rpt1+deb10u1) ...
Removing libcolord2:armhf (1.4.3-4) ...
Removing libdconf1:armhf (0.30.1-2) ...
Removing libgtk2.0-common (2.24.32-3+rpt1) ...
Removing libjson-glib-1.0-0:armhf (1.4.4-2) ...
Removing libjson-glib-1.0-common (1.4.4-2) ...
Removing liblcms2-2:armhf (2.9-3) ...
Removing libproxy1v5:armhf (0.4.15-5+deb10u1) ...
Processing triggers for libglib2.0-0:armhf (2.58.3-2+deb10u2) ...
No schema files found: removed existing output file.
Processing triggers for libc-bin (2.28-10+rpt2+rpi1) ...
Processing triggers for man-db (2.8.5-2) ...
Processing triggers for shared-mime-info (1.10-1) ...
Processing triggers for mime-support (3.62) ...
(Reading database ... (Reading database ... 5% (Reading database ... 10% dpkg: warning: files list file for package 'plymouth-themes' missing; assuming package has no files currently installed
(Reading database ... 15% dpkg: warning: files list file for package 'libxslt1.1:armhf' missing; assuming package has no files currently installed
(Reading database ... 20% (Reading database ... 25% (Reading database ... 30% (Reading database ... 35% (Reading database ... 40% (Reading database ... 45% (Reading database ... 50% (Reading database ... 55% (Reading database ... 60% (Reading database ... 65% (Reading database ... 70% (Reading database ... 75% (Reading database ... 80% (Reading database ... 85% (Reading database ... 90% (Reading database ... 95% (Reading database ... 100% (Reading database ... 38961 files and directories currently installed.)
Purging configuration files for libgtk-3-0:armhf (3.24.5-1+rpt2) ...
Purging configuration files for libgtk2.0-0:armhf (2.24.32-3+rpt1) ...
Purging configuration files for obsession (20140608-2) ...
Purging configuration files for adwaita-icon-theme (3.30.1-1) ...
Purging configuration files for openbox (3.6.1-8+rpt5) ...
Purging configuration files for at-spi2-core (2.30.0-7) ...
Purging configuration files for libgtk2.0-common (2.24.32-3+rpt1) ...
Purging configuration files for libgtk-3-common (3.24.5-1+rpt2) ...
Reading package lists...
Building dependency tree...
Reading state information...
The following packages will be REMOVED:
keyboard-configuration* libdrm-amdgpu1* libdrm-nouveau2* libdrm-radeon1*
libegl-mesa0* libegl1* libegl1-mesa* libepoxy0* libevdev2* libfontenc1*
libgbm1* libgl1* libgl1-mesa-dri* libglapi-mesa* libglu1-mesa* libglvnd0*
libglx-mesa0* libglx0* libgudev-1.0-0* libinput-bin* libinput10* libllvm9*
libmtdev1* libpciaccess0* libsensors-config* libsensors5* libunwind8*
libutempter0* libwacom-bin* libwacom-common* libwacom2* libwayland-server0*
libxaw7* libxcb-dri2-0* libxcb-dri3-0* libxcb-glx0* libxcb-present0*
libxcb-shape0* libxcb-sync1* libxcb-xfixes0* libxcomposite1* libxdamage1*
libxfont2* libxft2* libxkbfile1* libxmu6* libxpm4* libxshmfence1* libxt6*
libxv1* libxxf86dga1* x11-apps* x11-session-utils* x11-utils* x11-xkb-utils*
x11-xserver-utils* xbitmaps* xfonts-100dpi* xfonts-75dpi* xfonts-base*
xfonts-encodings* xfonts-scalable* xfonts-utils* xinit* xorg*
xorg-docs-core* xserver-common* xserver-xorg* xserver-xorg-core*
xserver-xorg-input-all* xserver-xorg-input-libinput*
xserver-xorg-input-wacom* xserver-xorg-legacy* xserver-xorg-video-all*
xserver-xorg-video-amdgpu* xserver-xorg-video-ati* xserver-xorg-video-fbdev*
xserver-xorg-video-nouveau* xserver-xorg-video-radeon*
xserver-xorg-video-vesa* xterm*
0 upgraded, 0 newly installed, 81 to remove and 207 not upgraded.
After this operation, 593 MB disk space will be freed.
(Reading database ... (Reading database ... 5% (Reading database ... 10% dpkg: warning: files list file for package 'plymouth-themes' missing; assuming package has no files currently installed
(Reading database ... 15% dpkg: warning: files list file for package 'libxslt1.1:armhf' missing; assuming package has no files currently installed
(Reading database ... 20% (Reading database ... 25% (Reading database ... 30% (Reading database ... 35% (Reading database ... 40% (Reading database ... 45% (Reading database ... 50% (Reading database ... 55% (Reading database ... 60% (Reading database ... 65% (Reading database ... 70% (Reading database ... 75% (Reading database ... 80% (Reading database ... 85% (Reading database ... 90% (Reading database ... 95% (Reading database ... 100% (Reading database ... 38941 files and directories currently installed.)
Removing xorg (1:7.7+19+b8) ...
Removing xserver-xorg (1:7.7+19+b8) ...
Removing xserver-xorg-video-all (1:7.7+19+b8) ...
Removing xserver-xorg-video-vesa (1:2.4.0-1+b1) ...
Removing xserver-xorg-video-ati (1:19.0.1-1) ...
Removing xserver-xorg-video-radeon (1:19.0.1-1) ...
Removing xserver-xorg-input-wacom (0.34.99.1-1+b6) ...
Removing xserver-xorg-video-nouveau (1:1.0.16-1) ...
Removing xserver-xorg-video-fbdev (1:0.5.0-1+b2) ...
Removing xserver-xorg-input-all (1:7.7+19+b8) ...
Removing xserver-xorg-input-libinput (0.28.2-2) ...
Removing x11-utils (7.7+4) ...
Removing libglu1-mesa:armhf (9.0.0-2.1) ...
Removing xserver-xorg-video-amdgpu (18.1.99+git20190207-1) ...
Removing libegl1-mesa:armhf (19.3.2-1~bpo10+1~rpt4) ...
Removing libinput10:armhf (1.12.6-2+deb10u1) ...
Removing libinput-bin (1.12.6-2+deb10u1) ...
Removing libevdev2:armhf (1.6.0+dfsg-1) ...
Removing xfonts-scalable (1:1.0.3-1.1) ...
Removing xfonts-base (1:1.0.5) ...
Removing libwacom-bin (0.32-1) ...
Removing libwacom2:armhf (0.32-1) ...
Removing libgudev-1.0-0:armhf (232-2+rpi1) ...
Removing libmtdev1:armhf (1.1.5-1+b2) ...
Removing xterm (344-1+deb10u2) ...
Removing libutempter0:armhf (1.1.6-3) ...
Removing libwacom-common (0.32-1) ...
Removing x11-xserver-utils (7.7+8+rpt1) ...
Removing xserver-xorg-legacy (2:1.20.4-1+rpt4+deb10u9) ...
Removing libxcb-shape0:armhf (1.13.1-2) ...
Removing libxcomposite1:armhf (1:0.4.4-2) ...
Removing x11-apps (7.7+7) ...
Removing libxft2:armhf (2.3.2-2) ...
Removing x11-session-utils (7.7+3) ...
Removing libxv1:armhf (2:1.0.11-1) ...
Removing libxxf86dga1:armhf (2:1.1.4-1) ...
Removing xbitmaps (1.1.1-2) ...
Removing xfonts-100dpi (1:1.0.4+nmu1) ...
Removing xfonts-75dpi (1:1.0.4+nmu1) ...
Removing xinit (1.4.0-1) ...
Removing xorg-docs-core (1:1.7.1-1.1) ...
Removing xserver-xorg-core (2:1.20.4-1+rpt4+deb10u9) ...
Removing keyboard-configuration (1.193~deb10u1) ...
Removing libgl1:armhf (1.3.0-7~bpo10+1) ...
Removing libglx0:armhf (1.3.0-7~bpo10+1) ...
Removing libglx-mesa0:armhf (19.3.2-1~bpo10+1~rpt4) ...
Removing libgl1-mesa-dri:armhf (19.3.2-1~bpo10+1~rpt4) ...
Removing libdrm-amdgpu1:armhf (2.4.100-4+rpi1~bpo10+1) ...
Removing libdrm-nouveau2:armhf (2.4.100-4+rpi1~bpo10+1) ...
Removing libdrm-radeon1:armhf (2.4.100-4+rpi1~bpo10+1) ...
Removing libegl1:armhf (1.3.0-7~bpo10+1) ...
Removing libegl-mesa0:armhf (19.3.2-1~bpo10+1~rpt4) ...
Removing libepoxy0:armhf (1.5.3-0.1) ...
Removing xfonts-utils (1:7.7+6) ...
Removing libxfont2:armhf (1:2.0.3-1) ...
Removing libfontenc1:armhf (1:1.1.3-1) ...
Removing libgbm1:armhf (19.3.2-1~bpo10+1~rpt4) ...
Removing libglapi-mesa:armhf (19.3.2-1~bpo10+1~rpt4) ...
Removing libglvnd0:armhf (1.3.0-7~bpo10+1) ...
Removing libllvm9:armhf (1:9.0.1-6+rpi1~bpo10+1) ...
Removing libpciaccess0:armhf (0.14-1) ...
Removing libsensors5:armhf (1:3.5.0-3) ...
Removing libsensors-config (1:3.5.0-3) ...
Removing libunwind8:armhf (1.2.1-10~deb10u1) ...
Removing libwayland-server0:armhf (1.16.0-1) ...
Removing xserver-common (2:1.20.4-1+rpt4+deb10u9) ...
Removing x11-xkb-utils (7.7+4) ...
Removing libxaw7:armhf (2:1.0.13-1+b2) ...
Removing libxcb-dri2-0:armhf (1.13.1-2) ...
Removing libxcb-dri3-0:armhf (1.13.1-2) ...
Removing libxcb-glx0:armhf (1.13.1-2) ...
Removing libxcb-present0:armhf (1.13.1-2) ...
Removing libxcb-sync1:armhf (1.13.1-2) ...
Removing libxcb-xfixes0:armhf (1.13.1-2) ...
Removing libxdamage1:armhf (1:1.1.4-3+b3) ...
Removing libxkbfile1:armhf (1:1.0.9-2) ...
Removing libxmu6:armhf (2:1.1.2-2+b3) ...
Removing libxpm4:armhf (1:3.5.12-1+deb10u2) ...
Removing libxshmfence1:armhf (1.3-1) ...
Removing libxt6:armhf (1:1.1.5-1+b3) ...
Removing xfonts-encodings (1:1.0.4-2) ...
dpkg: warning: while removing xfonts-encodings, directory '/usr/share/fonts/X11/encodings/large' not empty so not removed
Processing triggers for mime-support (3.62) ...
Processing triggers for libc-bin (2.28-10+rpt2+rpi1) ...
Processing triggers for man-db (2.8.5-2) ...
Processing triggers for fontconfig (2.13.1-2) ...
(Reading database ... (Reading database ... 5% (Reading database ... 10% dpkg: warning: files list file for package 'plymouth-themes' missing; assuming package has no files currently installed
(Reading database ... 15% dpkg: warning: files list file for package 'libxslt1.1:armhf' missing; assuming package has no files currently installed
(Reading database ... 20% (Reading database ... 25% (Reading database ... 30% (Reading database ... 35% (Reading database ... 40% (Reading database ... 45% (Reading database ... 50% (Reading database ... 55% (Reading database ... 60% (Reading database ... 65% (Reading database ... 70% (Reading database ... 75% (Reading database ... 80% (Reading database ... 85% (Reading database ... 90% (Reading database ... 95% (Reading database ... 100% (Reading database ... 36440 files and directories currently installed.)
Purging configuration files for xinit (1.4.0-1) ...
Purging configuration files for xfonts-100dpi (1:1.0.4+nmu1) ...
dpkg: warning: while removing xfonts-100dpi, directory '/usr/share/fonts/X11/100dpi' not empty so not removed
Purging configuration files for xserver-xorg (1:7.7+19+b8) ...
Purging configuration files for libgl1-mesa-dri:armhf (19.3.2-1~bpo10+1~rpt4) ...
Purging configuration files for xserver-xorg-core (2:1.20.4-1+rpt4+deb10u9) ...
rm: cannot remove '/var/log/Xorg.*.log': No such file or directory
rm: cannot remove '/var/log/Xorg.*.log.old': No such file or directory
Purging configuration files for libsensors-config (1:3.5.0-3) ...
Purging configuration files for libxxf86dga1:armhf (2:1.1.4-1) ...
Purging configuration files for x11-apps (7.7+7) ...
Purging configuration files for xfonts-utils (1:7.7+6) ...
dpkg: warning: while removing xfonts-utils, directory '/usr/share/fonts/X11/util' not empty so not removed
Purging configuration files for x11-xserver-utils (7.7+8+rpt1) ...
Purging configuration files for libfontenc1:armhf (1:1.1.3-1) ...
Purging configuration files for xfonts-base (1:1.0.5) ...
dpkg: warning: while removing xfonts-base, directory '/usr/share/fonts/X11/misc' not empty so not removed
Purging configuration files for x11-utils (7.7+4) ...
Purging configuration files for x11-session-utils (7.7+3) ...
Purging configuration files for libglu1-mesa:armhf (9.0.0-2.1) ...
Purging configuration files for xterm (344-1+deb10u2) ...
Purging configuration files for xfonts-75dpi (1:1.0.4+nmu1) ...
dpkg: warning: while removing xfonts-75dpi, directory '/usr/share/fonts/X11/75dpi' not empty so not removed
Purging configuration files for keyboard-configuration (1.193~deb10u1) ...
Purging configuration files for xserver-xorg-legacy (2:1.20.4-1+rpt4+deb10u9) ...
Purging configuration files for xfonts-scalable (1:1.0.3-1.1) ...
dpkg: warning: while removing xfonts-scalable, directory '/usr/share/fonts/X11/Type1' not empty so not removed
Processing triggers for fontconfig (2.13.1-2) ...
Deleting /opt/volumiokiosk.sh
Deleting /data/volumiokiosk
Deleting /data/volumiokioskextensions
Deleting /lib/systemd/system/volumio-kiosk.service
Deleting /etc/X11/xorg.conf.d/95-touch_display-plugin.conf
Deleting /etc/X11/xorg.conf.d/99-vc4.conf
Enabling login prompt
Done
An error occurred while installing the plugin Error
Removing plugin directory /data/plugins/user_interface/touch_display
Removing temporary directory /tmp/touch_display-IsldLUaEgh
I was able to solve this issue by re-initializing my SD card with a fresh download and then following these instructions.
Sometimes this happens, that the first try fails.
When this happens, run:
sudo apt-get updateHi @dsolano04 and @gvolt,
I’ve been working on making the Hyperpixel 4 Touch Screen work with a Rpi4 for some days now.
Until mid 2023 I had it working perfectly, and did the operation multiple times. But now even after doing some fresh installs, I never get the screen on (only the backlight).
Here was my old process to get it running :
sudo apt install apt-utils
sudo apt install device-tree-compiler
sudo apt install rpi.gpio
sudo git clone GitHub - pimoroni/hyperpixel4: Driver for the Pimoroni HyperPixel 4.0" Touchscreen Display -b pi4-i2c-fix
cd hyperpixel4
sudo ./install.sh
I tried doing as you listed here starting from a fresh install but without success…
sudo apt-get update
sudo apt-get install apt-utils
sudo apt-get install device-tree-compiler
git clone GitHub - pimoroni/hyperpixel4: Driver for the Pimoroni HyperPixel 4.0" Touchscreen Display -b pi4
cd hyperpixel4
sudo ./install.sh
sudo apt-get install rpi.gpio
gpio=0-25=a2
hyperpixel4.init starts but stays inactive for some reason:
● hyperpixel4-init.service - HyperPixel 4.0" LCD Display Initialization
Loaded: loaded (/etc/systemd/system/hyperpixel4-init.service; enabled; vendor preset: enabled)
Active: inactive (dead) since Wed 2025-01-15 23:49:37 CET; 25min ago
Main PID: 557 (code=exited, status=0/SUCCESS)Jan 15 23:49:35 cloudatlas systemd[1]: Starting HyperPixel 4.0" LCD Display Initialization…
Jan 15 23:49:37 cloudatlas systemd[1]: hyperpixel4-init.service: Succeeded.
Jan 15 23:49:37 cloudatlas systemd[1]: Started HyperPixel 4.0" LCD Display Initialization.
In /boot/config.txt I only have the following in the i2s settings:
dtoverlay=hyperpixel4
enable_dpi_lcd=1
dpi_group=2
dpi_mode=87
dpi_output_format=0x7f216
dpi_timings=480 0 10 16 59 800 0 15 113 15 0 0 0 60 0 32000000 6
Adding gpio=0-25=a2 shuts the screen backlight off…
● hyperpixel4-init.service - HyperPixel 4.0" LCD Display Initialization
Loaded: loaded (/etc/systemd/system/hyperpixel4-init.service; enabled; vendor preset: enabled)
Active: inactive (dead) since Thu 2025-01-16 00:47:30 CET; 1min 29s ago
Main PID: 567 (code=exited, status=0/SUCCESS)Jan 16 00:47:27 volumio systemd[1]: Starting HyperPixel 4.0" LCD Display Initialization…
Jan 16 00:47:29 volumio hyperpixel4-init[567]: /usr/bin/hyperpixel4-init:12: RuntimeWarning: This channel is already in use, continuing anyway. Use GPIO.setwarnings(False) to disable warnings.
Jan 16 00:47:29 volumio hyperpixel4-init[567]: GPIO.setup([CLK, MOSI, CS], GPIO.OUT)
Jan 16 00:47:30 volumio systemd[1]: hyperpixel4-init.service: Succeeded.
Jan 16 00:47:30 volumio systemd[1]: Started HyperPixel 4.0" LCD Display Initialization.
As I have some but limited understading of all what’s going on here, did I miss a simple step or is my problem different from the one of @dsolano04 ?
Hello,
I’m trying to achieve this but with the ElecLab 7.4" screen instead of the 8".
I’ve flashed my Card with the latest Volumio and editted the userconfig.txt files trying many times.
The directions say the following:
*When use RPI4, make sure that VC4-KMS-V3D is prohibited in config.txt
#dtoverlay = VC4-KMS-V3D
Connect to RPI, hdmi_drive must be set to 1
Modify /boot/config.txt
hdmi_force_hotplug=1
hdmi_ignore_edid=0xa5000080
hdmi_group=2
hdmi_mode=87
hdmi_timings=1280 0 64 2 18 400 0 10 3 42 0 0 0 60 0 37330000 3
hdmi_drive=1*
When I boot on this screen nothing boots. Anyone half any idea what I’m doing wrong?
I’ve also tried this userconfig.txt to no avail:
hdmi_cvt=1280 400 60
hdmi_ group=2
hdmi_mode=87
hdmi_drive=1
display rotate=1
hdmi_ force _mode=1
framebuffer_width=1280
framebuffer_height=400
max_framebuffer_width=1280
max_framebuffer_height=1280
dtoverlay = VC4-KMS-V3D
disable_overscan=1
Thanks for your help. I am obviously not a coder.
Revert all changes you made to “/boot/config.txt”, “/boot/volumioconfig.txt” or “/boot/userconfig.txt” and try adding the following to “/boot/userconfig.txt”:
hdmi_group=2
hdmi_mode=87
hdmi_ignore_edid=0xa5000080
hdmi_timings=1280 0 64 2 18 400 0 10 3 42 0 0 0 60 0 37330000 3
hdmi_drive=1
This is mainly the same as you probably already tried, but without dtoverlay = VC4-KMS-V3D.
Is there any particular reason why you could not use with the recent VolumioOS the shipped kernel module and the overlay directly? What is the technical reason behind rebuilding the module from the GitHub repo you referenced?
Kind Regards,
Hi @nerd,
Thanks for your suggestion. I simply did not know there was another way around to do this. Since end of 2020 I’ve been doing it this way to make it work and never had any problem…
I tried doing the following, tell me if I did it right:
1 - fresh intall of Volumio on a RPi 4 with a hyperpixel 4 (only the bare minimum is configured)
2 - install touch plugin and reboot
3 - using nano /boot/userconfig.txt add
dtoverlay=vc4-kms-v3d
dtoverlay=vc4-kms-dpi-hyperpixel4
4 - reboot
I still only have the backlight on…
I added to /boot/userconfig.txt
dtdebug=on
and here is the output of sudo vcdbg log msg:
002675.116: arasan: arasan_emmc_open
002675.286: arasan: arasan_emmc_set_clock C0: 0x00800000 C1: 0x000e0047 emmc: 200000000 actual: 390625 div: 0x00000100 target: 400000 min: 400000 max: 400000 delay: 5
002780.061: arasan: arasan_emmc_set_clock C0: 0x00800000 C1: 0x000e0047 emmc: 200000000 actual: 390625 div: 0x00000100 target: 400000 min: 400000 max: 400000 delay: 5
002780.148: arasan: arasan_emmc_set_clock C0: 0x00800f00 C1: 0x000e0047 emmc: 200000000 actual: 390625 div: 0x00000100 target: 400000 min: 390000 max: 400000 delay: 5
002809.006: arasan: arasan_emmc_set_clock C0: 0x00800f06 C1: 0x000e0207 emmc: 200000000 actual: 50000000 div: 0x00000002 target: 50000000 min: 0 max: 50000000 delay: 1
002912.208: brfs: File read: /mfs/sd/config.txt
002912.375: brfs: File read: 269 bytes
002913.925: brfs: File read: /mfs/sd/volumioconfig.txt
002914.176: brfs: File read: 366 bytes
002916.711: brfs: File read: /mfs/sd/userconfig.txt
002917.024: brfs: File read: 157 bytes
002941.575: HDMI0:EDID error reading EDID block 0 attempt 0
002942.591: HDMI0:EDID giving up on reading EDID block 0
002954.407: HDMI1:EDID error reading EDID block 0 attempt 0
002955.422: HDMI1:EDID giving up on reading EDID block 0
002959.510: brfs: File read: /mfs/sd/config.txt
002959.669: brfs: File read: 269 bytes
002961.064: brfs: File read: /mfs/sd/volumioconfig.txt
002961.286: brfs: File read: 366 bytes
002963.806: brfs: File read: /mfs/sd/userconfig.txt
003445.772: gpioman: gpioman_get_pin_num: pin DISPLAY_DSI_PORT not defined
003446.529: gpioman: gpioman_get_pin_num: pin DISPLAY_DSI_PORT not defined
003448.678: *** Restart logging
003448.698: brfs: File read: 157 bytes
003457.400: hdmi: HDMI0:EDID error reading EDID block 0 attempt 0
003458.417: hdmi: HDMI0:EDID giving up on reading EDID block 0
003463.463: hdmi: HDMI0:EDID error reading EDID block 0 attempt 0
003464.481: hdmi: HDMI0:EDID giving up on reading EDID block 0
003476.207: hdmi: HDMI1:EDID error reading EDID block 0 attempt 0
003477.223: hdmi: HDMI1:EDID giving up on reading EDID block 0
003482.265: hdmi: HDMI1:EDID error reading EDID block 0 attempt 0
003483.283: hdmi: HDMI1:EDID giving up on reading EDID block 0
003483.299: hdmi: HDMI:hdmi_get_state is deprecated, use hdmi_get_display_state instead
003483.312: HDMI0: hdmi_pixel_encoding: 300000000
003483.326: HDMI1: hdmi_pixel_encoding: 300000000
009447.168: brfs: File read: /mfs/sd/volumio.initrd
009447.203: Loaded ‘volumio.initrd’ to 0x0 size 0x1b6dbef
009489.645: initramfs loaded to 0x2d492000 (size 0x1b6dbef)
009489.724: dtb_file ‘bcm2711-rpi-4-b.dtb’
009489.770: brfs: File read: 28761071 bytes
009508.524: brfs: File read: /mfs/sd/bcm2711-rpi-4-b.dtb
009508.559: Loaded ‘bcm2711-rpi-4-b.dtb’ to 0x100 size 0xdb5c
009543.005: brfs: File read: 56156 bytes
009567.929: brfs: File read: /mfs/sd/overlays/overlay_map.dtb
009620.377: brfs: File read: 5451 bytes
009621.271: brfs: File read: /mfs/sd/config.txt
009621.505: brfs: File read: 269 bytes
009623.436: brfs: File read: /mfs/sd/volumioconfig.txt
009623.652: dtparam: audio=on
009633.913: dtparam: i2c_arm=on
009655.756: brfs: File read: 366 bytes
009659.835: brfs: File read: /mfs/sd/userconfig.txt
009662.430: brfs: File read: 157 bytes
009694.860: brfs: File read: /mfs/sd/overlays/vc4-kms-v3d-pi4.dtbo
009850.768: Loaded overlay ‘vc4-kms-v3d-pi4’
010229.779: brfs: File read: 3913 bytes
010260.699: brfs: File read: /mfs/sd/overlays/vc4-kms-dpi-hyperpixel4.dtbo
010290.848: Loaded overlay ‘vc4-kms-dpi-hyperpixel4’
010573.751: brfs: File read: 3853 bytes
010579.300: brfs: File read: /mfs/sd/cmdline.txt
010579.546: Read command line from file ‘cmdline.txt’:
010579.596: 'splash plymouth.ignore-serial-consoles dwc_otg.fiq_enable=1 dwc_otg.fiq_fsm_enable=1 dwc_otg.fiq_fsm_mask=0xF dwc_otg.nak_holdoff=1 quiet console=serial0,115200 console=tty1 imgpart=UUID=fb80cb44-b4d3-4b36-be35-613cba0a09fb imgfile=/volumio_current.sqsh
010953.743: brfs: File read: 579 bytes
012609.480: brfs: File read: /mfs/sd/kernel7l.img
012609.518: Loaded ‘kernel7l.img’ to 0x8000 size 0x7789d0
012609.571: Device tree loaded to 0x2d483700 (size 0xe888)
012615.235: gpioman: gpioman_get_pin_num: pin SDCARD_CONTROL_POWER not defined
012719.794: sdram: sdram refresh 1562->3124 (2)
014428.367: vchiq_core: vchiq_init_state: slot_zero = 0xcd580000, is_master = 1
014434.485: TV service:host side not connected, dropping notification 0x00000002, 0x00000002, 0x00000004
Again, as I am no expert in this, I may have missed a step which leads to my problem…
Did I correctly enable the KMS drivers ?
Best regards,
I forgot to mention that having
dtoverlay=vc4-kms-v3d
in /boot/userconfig.txt or not, did not change anything.
And here is the content of /boot/config.txt:
DO NOT EDIT THIS FILE
APPLY CUSTOM PARAMETERS TO userconfig.txt
initramfs volumio.initrd
gpu_mem=128
gpu_mem_256=32
gpu_mem_512=32
gpu_mem_1024=128
max_usb_current=1
[pi5]
usb_max_current_enable=1
[all]
include volumioconfig.txt
include userconfig.txt
of /boot/volumioconfig.txt:
DO NOT EDIT THIS FILE
APPLY CUSTOM PARAMETERS TO userconfig.txt
[cm4]
dtoverlay=dwc2,dr_mode=host
otg_mode=1
[pi5]
dtoverlay=vc4-kms-v3d-pi5dtparam=uart0_console # Disabled by default
dtparam=nvme
dtparam=pciex1_gen=2
[all]
arm_64bit=0
dtparam=audio=on
audio_pwm_mode=2
dtparam=i2c_arm=on
disable_splash=1
hdmi_force_hotplug=1
force_eeprom_read=0
I also tried uninstalling the touch plugin, rebooting, reinstalling it, rebotting again, but still no change.
As I’m writing this reply I noticed the pi5 in dtoverlay in the volumioconfig.txt. I modified the file as follows to see if it would help:
DO NOT EDIT THIS FILE
APPLY CUSTOM PARAMETERS TO userconfig.txt
[cm4]
dtoverlay=dwc2,dr_mode=host
otg_mode=1
[pi5]
dtoverlay=vc4-kms-v3d
dtoverlay=vc4-kms-dpi-hyperpixel4dtoverlay=vc4-kms-v3d-pi5 # Disabled
dtparam=uart0_console # Disabled by default
dtparam=nvme # Disabled
dtparam=pciex1_gen=2 # Disabled
[all]
arm_64bit=0
dtparam=audio=on
audio_pwm_mode=2
dtparam=i2c_arm=on
disable_splash=1
hdmi_force_hotplug=1
force_eeprom_read=0
Still no luck, but at this point I don’t really know exactly what I’m doing.
Hey @l_italien_adg,
Method change is actually stated on Pimoroini’s repo:
In order to disable something in the VolumioOS startup bundle you will need to place the # character at the very beginning of a line. Placing it at the end simply adds a comment to it.
Example:
dtoverlay=some_nitty_overlay # I am a comment only
# dtoverlay=some_nitty_overlay # I am a comment and disabled
Perhaps this is a matter of formatting of markdown in your response showing this differently:
When using special characters like # prepend it with the escape (backslash) character \#
The configuration scope is determined by targeting of BCM peripherals and as such [pi5] only affects devices identified with 2712 whilst [pi4] 2711 and so on. Placing scope [all] targets all SBCs irrespective of the BCM ARM peripheral inclusion in BCM28xx chip.
In your case, commenting out overlays [pi5] makes no difference as your SBC is based on BCM2711 which simply does no know what vc4 rpi1 target is.
You can see the details here: https://www.raspberrypi.com/documentation/computers/processors.html
However, problem with the Hyperpixel screen is that it is very greedy and hijacking most of the gpio pins, typically used by SPI, I2S, I2C communication.
Test it by commenting out reference to the I2C bus in /boot/volumioconfig.txt and change
dtparam=i2c_arm=on
to
# dtparam=i2c_arm=on
Kind Regards,
Hello. How does the plugin handle USB keyboard input? I want to connect a keypad to my pi for play controls, but the methods that use terminal commands aren’t going to work when there’s a UI on the screen.
I’ve tried connecting a keyboard and just pushing buttons. For media keys, sometimes I have volume control, sometimes I don’t. I had a rotary encoder connected through the GPIO plugin, and strangely it had the same problem. The only other keys that do anything are basic window navigation stuff like tab and enter.
System Version: 3.785
Touch Display 3.5.1
Raspberry Pi 4
The Touch Display plugin doesn’t handle keyboard inputs (apart from waking up the screen). The plugin’s purpose is to display Volumio’s UI on a locally connected (touch)screen.
You could use triggerhappy to assign actions to keys. You may have a look at the configuration file “/etc/triggerhappy/triggers.d/audio.conf”. Accessing the file is possible over an sftp connection after enabling SSH access to Volumio.
I read that post. Triggerhappy is just assigning macros to type commands in the open console, right? I tried typing those commands myself and nothing happened. Is there a console running somewhere behind the UI to accept the keystrokes? I can alt+tab, but there are no other windows to switch to.
